Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Round Granules 200 Kg / Batch Wet Granulator Machine
Specifications
Brand Name :
YIGAN
Model Number :
QZL
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiation
Supply Ability :
30 sets per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Packed in film firstly, and then reinforced with wooden case for outer packing
product name :
wet granulator machine/ball granulator
granulator type :
wet granulator machine
processing object :
granules
discharging :
by cylinder
speed control :
by transducer
finished product :
round granules
Description

QZL Series Spheroidzing Pellet Machine ball granulator wet granulator machine

Applications


1. Making extruded segments or moist granules into spheres

2. Wet spheronization for Food, Chemical and Phamaceutical products;

3. Capacity: 2.5-200 kg/batch

4. GMP design

Working principle
QZL Series Spheroidzing Pellet Machine ball granulator wet granulator machine is the extensively used processor for converting extruded particles or moist granules from a mixer /granulator into perfect spheres in food, chemical and pharmaceutical industries.
Particles are fed into the spinning friction plate, which throws them against the inside wall of the cylinder. Extruded particles are quickly broken into segments approximately one diameter long. Centrifugal and gravitational forces create a mechanically fluidized ring of particles. Collisions with the wall, friction plate and other particles result in the plastic deformation of each granule, quicky creating a spherical shape. The desired shape for a specific application is time and formulation dependent and is achieved, predictably and repeatedly, in a brief period called the "spheronization time".

Round Granules 200 Kg / Batch Wet Granulator Machine

Technical Parameters

Specification 230 400 500 700 1000 1300
Power ( Kw ) 0.75 2.2 3 3.7 5.5 7.5
Capacity ( kg/h ) 2.5-4 5-8 8-16 40-80 70-150 100-300

All dates for reference only. According to the material features, we have the right to change but not notice, pardon!
