Specifications
Brand Name :
QYT
Model Number :
WPC-J015SBR
Certification :
CE, FCC, RoHS, IP67 IP69K
Place of Origin :
Guangdong, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability :
5000 Set/Sets per Month
Delivery Time :
3-10 Business Days
Packaging Details :
Foam + Carton
IP Rate :
IP67 / IP68 / IP69K
Size :
15" Led
Resolution :
1024 x 768
Processor :
Intel Celeron Quad Core J1900 2.0GHz
Memory :
DDR3L 1333MHz 4GB, Up to 8GB
Harddisk :
32G / 64G / 128G / 250G / 500G SSD Optional
I/O Interface :
VGA/HD-MI/LAN/USB/RS232
Touchscreen :
Resistive Touch / Capacitive Touch
Power Input :
DC 12V~24V / DC 9V~36V Optional
Operating System :
Win7/8/10/Linux/Ubuntu
Description

Factory 15" industrial automation fanless touch panel pc ip67 water resistant for outdoor

Feature

The waterproof pc is ideal for applications such as marine/Sailing boat, medical equipment, humid production equipment, food Industry, chemical manufacturing and other outdoor applications.

1. 15" TFT LED, adopt 5 wire resistive touch screen, high precision, durable, anti-interference.

2. Intel Celeron Quad Core J1900 2.0GHz

3. 1x DDR3L 1333MHz 4GB. Max up to 8GB

4. Multi ports optional:HDMI/LAN/USB/COM

5. VESA Mounting: 100 x 100 mm

6. DC12V~24V Input (+9V～36V wide voltage optional)

7. Wide range: -20°C to 70°C working temperature range.

8. 1000nits sunlight readable optional

WPC-J015SBR
System CPU Intel Celeron Quad Core J1900 2.0GHz
L2 Cache 2MB
Chipsets Intel Bay Trail SOC
Memory DDR3L 1333MHz 4GB, Up to 8GB
Harddisk 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
Graphics Intel HD Graphics
Network Intel 82583V 1000 Mbps port
Audio Realtek ACL662 Audio controller
Operation System Windows7 / 8 / 10, Linux, Unix, QNX
I / O VGA 1 x VGA / 1 x HD-MI ( Optional )
LAN 1 x LAN ( Optional )
USB 3 x USB2.0 / 1 x USB3.0 ( Optional )
COM 2 x RS232 ( Optional )
Wireless Network WiFi + Bluetooth ( Optional )
Other I/O Interface 1 x Power Switch
LCD Panel Panel Size 15" Led
Resolution 1024 x 768
Aspect Ratio 4:3
Display Brightness 350 cd/m2
Contrast Ratio 1000:1
Colors 16.7M , 72% NTSC
Response Time 30 (Typ.)(Tr+Td) ms
Viewing Angle 89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
Touch screen Touch Screen Type 5 wire resistive touch
Transmittance >85%
Response Time <5ms
Surface Hardness ≥3H
Supply Voltage 5.0V DC
Touch Life ≧ 1000W
Institutional Material Aluminum Alloy Shell
Color Silver / Black ( optional )
VESA Mounting VESA: 100 x 100 mm
Waterproof Rate IP67 / IP68 / IP69K
Product Dimension 360 x 283 x 50 mm
Cut-out Size /
Packing Size 460 x 180 x 400 mm
Gross Weight 7.0 KG
Power and Environment Operating Temperature -10~60°C
Storage Temperature -20~80°C(-22~176°F)
Relative Humidity 5%~95%@40°C, non-condensing
Vibration Range 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
External Power Supply AC 100 - 240V~50/60Hz,1.5A
Working Voltage DC 12V~24V / optional(+9V~36V)
Power Consumption ≦30W



151515

OEM/ODM

1. size from 7''-21.5'' available

2. Processor--Intel J1900/ I3/I5/I7 .....etc lower consumption board

3. Capacitive touch / Resistive touch or without touch

4. 1000nits, 1500nits high brightness for sunlight readable

5. DC 9V～36V wide voltage input

Applications

Industrial automation

human Machine Interface

Marine control system

welding industry

supervisory control

numerical control device

FAQ

1. Q: Are you a manufacturer or trading company?
A: We're a professional manufacturer with more than 10 years experience in industrial automation field.

2. Q: Do you provide ODM/OEM or customized service?
A: Yes,we support OEM&ODM service, let you get the products you want exactly.

3. Q: What certifications do you have?
A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.

4. Q: How long is the warranty?
A: Our factory promised warranty is 1 year.

5. Q:What is the lead time?
A: 3 business days for samples order, 15 business days for mass production.

6. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
