Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series
Specifications
Brand Name :
Xinming
Model Number :
X(AM)Z120/1000-30U
Certification :
ISO9001, CE, SGS
Place of Origin :
Made in China
MOQ :
1 Set
Price :
Negotable
Payment Terms :
D/A, D/P, T/T, Western Union
Supply Ability :
1000 sets/per month
Delivery Time :
Within 25-35 working days after down payment
Packaging Details :
Standard packing
Production Capacity :
High Efficiency
Voltage :
3ph/380V50HZ,3ph/415V/50HZ, 3ph/440V/50HZ or other
Filter Material :
FRPP
Power :
4.0KW
Power Type :
Automatic hydraulic press and ope
Control :
Siemens Control
Description

Cost Effective Wholesale Fully Automatic 1000 Series Membrane Filter Press Machine

Even when it is difficult to filter materials, the filter press still has a good effect, and easy to do anti-corrosion treatment, its structure is simple, easy to operate, lower than other filters. Therefore, choosing filter press as dehydration equipment is your best choice.

At present, filter press has been widely used in chemical industry, pharmaceutical, metallurgy, ceramics, sugar, pigment, dye, cement, silicates and other industries and municipal and industrial sludge dewatering and other aspects.

Filter plate is made of reinforced polypropylene material, which has the characteristics of stable chemical performance, corrosion resistance, acid resistance, alkali resistance, salt resistance, non-toxic and tasteless, light weight, high strength, good toughness, low labor intensity of unloading operation.

Technical Data

Model X(AM)Z120/1000-30U
Filter Area(m2) 120
Plate Size(mm) 1000*1000
Cake Thickness(mm) 30
Filter Chamber Volume(L) 1816
Plate Qty(pcs) 69
Filtration Pressure(MPa) ≥0.6
Motor Power(Kw) 4.0
Weight(kg) 7644
Dimensions L*W*H(mm) 6500*1500*1400

Foundation Size L/B/D/H(mm)

 5580/800/1480/900/485

Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series

Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series

Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series

Feature

1.Simplified structure

2.Remote automatic operation and control

3.Solid&liquid separation

4.Suitable for 120 m2 filtration area

APPLATION FIELD:

Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series

Chengdu Xinming Environmental Protection Co., Ltd is a professional equipment manufacturing enterprises , specialized in design ,manufacture and sales of various filtration equipment as well as comprehensive filtration solutions and projects. We have a sound quality assurance system and advanced testing equipment ,can be from raw material into the factory warehousing , processing , assembly , to the whole machine factory supervision and control throughout the process . we have the high-class R&D personnel , experienced workers and high qualified sales team , we are devoting to provide best products for our clients

RFQ:

Q1: What is the Warranty for the machines?

A1: 12 months for free.

Q2: When can I get the price?

A2: Within 24 hours, if urgent, please directly call us.

Q3: Whether the machine price can be more discount?

A3: In general, our MOQ is 1set with very reasonable price, but if large order, we also can apply to our Manager to appropriately give you a little discount.

Q4: How to ask quotation?

A4: Please directly tell us which item you are interested in, or note us what tpye of materials, and how many tons of materials you want to treat per day or per hour, then we will send you quotation as soon as we can.

Q5: How long will it take to receive my products?

A5: As a general rule, it will take one 25-35 days for us to produce.

Cost Effective Membrane Filter Press Machine Fully Automatic 1000 Series

For your choose

Model

Filter area

(M2)

 Filter Chamber Volume(L) Plate Qty(pcs)

Pressure

(Mpa)

Power

(KW)

Weight

(Kg)

Dimension

L*W*H(MM)
XMG30/870 30 498 23 ≥0.8 4.0 3046 3880*1250*1300
XMG40/870 40 623 29 3593 4270*1250*1300
XMG50/870 50 789 37 4057 4790*1250*1300
XMG60/870 60 955 45 4597 5310*1250*1300
XMG70/870 70 1121 53 5136 5830*1250*1300
XMG80/870 80 1287 61 5636 6350*1250*1300
XMG50/1000 50 776 27 ≥0.8 4.0 4352 4270*1250*1300
XMG60/1000 60 943 33 4480 4770*1250*1300
XMG70/1000 70 1109 39 5263 5130*1250*1300
XMG80/1000 80 1275 45 5719 5560*1250*1300
XMG100/1000 100 1608 57 6555 6410*1250*1300
XMG120/1000 120 1941 69 7466 7260*1250*1300
XMG80/1250 80 1560 29 ≥0.8 5.5 10900 4830*1800*1600
XMG100/1250 100 1975 37 11750 5440*1800*1600
XMG120/1250 120 2391 45 12600 6060*1800*1600
XMG150/1250 150 2911 55 13620 6820*1800*1600
XMG160/1250 160 3119 59 14470 7130*1800*1600
XMG200/1250 200 3847 73 15320 8200*1800*1600
XMG240/1250 240 4679 89 16170 9420*1800*1600
XMG250/1250 250 4783 91 17020 9570*1800*1600
XMG200/1500 200 3809 49 ≥0.8 11.0 26120 7140*2200*1820
XMG250/1500 250 4723 61 26930 7730*2200*1820
XMG300/1500 300 5637 73 28160 8720*2200*1820
XMG350/1500 350 6551 85 29600 10110*2200*1820
XMG400/1500 400 7618 99 31500 11260*2200*1820
XMG450/1500 450 8532 111 33400 12250*2200*1820
XMG500/1500 500 9446 123 33380 13240*2200*1820
XMG600/2000 600 11901 85 ≥0.8 15 54164 13030*3000*2500
XMG700/2000 700 13838 99 58300 14390*3000*2500
XMG800/2000 800 14945 107 62460 15770*3000*2500
XMG900/2000 900 17713 127 66620 17150*3000*2500
XMG1000/2000 1000 19651 141 70780 18530*3000*2500
