HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment
Specifications
Brand Name :
Hinming
Model Number :
XMBL-9
Certification :
ISO9001, CE
Place of Origin :
Made in China
MOQ :
1 Sets
Price :
USD 8000.00-12000.00 / Sets
Payment Terms :
L/C, T/T, Western Union, D/P
Supply Ability :
10000 Sets/ per Year
Delivery Time :
Within 15-20 working days after receive 30% down payment
Packaging Details :
Standard Packing
Material :
Stainless Steel 304/316
Voltage :
380V/220V/400V, Customized
Power(W) :
1.5KW-7.5KW
Dimension(L*W*H): :
1350x600x1000(mm)
Type :
Automatic Filter Press
Function :
Wine and oil stainless steel filter press machine
Filter Pressure :
≥0.8MPa
Application :
Slurry Water Treatment
Filter Area :
60m2
Material of bag :
PP
Cartridge Size :
90*1000 mm
Description

HM XMCD-300-30 Precise Liquid Filter Machine for Slurry Water Treatment

HM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water TreatmentHM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water TreatmentHM XMCD-300-30 Precise Liquid Filter Machine For Slurry Water Treatment

Stainless Steel Laminated Precision Filter:

Stainless steel precise liquid filter is the latest developed laminated precise filter. The filter is featured with large filter area and high efficiency, and widely be used in chemical, pharmacy, beer, mineral water, petroleum and other industries. It is the new equipment to filter the tiny impurities for various liquid. The filter is made of SS304 and SS316L. It is the multipurpose filtration equipment with stable performance, anti-corrosion, durable service, neoteric structure, easy operation, energy saving and high adaptation.
Model Layer QTY Filter Area/m2 Filter Precision/um Filter element size/mm

Flow

t/h

 Working pressure/Mpa Power/kw Volume/L
DZCD-300 10 0.7 0.22-100 306 4 0.2-0.4 0.75 3
14 1 6 3.2
20 1.4 8 1.1 6
30 2.1 12 1.5 9
40 2.8 16 2.2 12
DZCD-400 14 1.75 406 10 13
20 2.5 14 15
30 3.75 21 20
40 5 28 3 30
DZCD-500 20 3.9 506 25 4 35
40 7.8 50 70
DZCD-550 20 4.75 566 35 40
40 9.5 70 80
DZCD-600 20 5.6 606 35 5.5 100
40 11.2 70 200
DZCD-700 20 7.6 706 45 120
40 15.2 90 7.5 240
DZCD-800 20 10 806 65 5.5 180
40 20 130 7.5 300

Features of Laminated Precision Filter:

A sealed chamber will be formed by the inner filtering device with the bottom. There are two inlets and one outlet going through the bottom and connecting with the inner chamber. The filtering device includes severaly layers of filtering screens, and deivded the chamber into 2 chambers: original fluid chamber and the filtrate chamber. The inlets are connecting with the orginal fluid chamber, and the outlet is connecting with the filtrate chamber. The filter is featured with large filter area, high speed, large flow and high efficiency.

The filter screens are laminated. The customer can select the model according to the flow, and we could customize the filter for materials needs hear retaining. The feeding pump is flexible according to your demands. If the filter and the pump are installed on the moving platform, after cleaning it can be used for filtering other liquids, so one machine has different uses.

In some industries, such as: chemical, pharmacy, food, biochemical, environmental protection etc. some liquids might has high solid content, if frequent washing is needed, it must will influence the production cycle and efficiency, so we could extend the chamber volume to store more solid impurities to meet the actual needs. Additionally, according to the nature of material, the seal also can be customiszed. For example, for the organic solvent, we might use cladding rubber seals to avoid leakage and make sure the normal production.

Chengdu Hinming Environmental Protection Co., Ltd is a professional equipment manufacturing enterprises , specialized in design ,manufacture and sales of various filtration equipment as well as comprehensive filtration solutions and projects. We have a sound quality assurance system and advanced testing equipment ,can be from raw material into the factory warehousing , processing , assembly , to the whole machine factory supervision and control throughout the process . we have the high-class R&D personnel , experienced workers and high qualified sales team , we are devoting to provide best products for our clients
