Specifications
Brand Name :
Xinming
Model Number :
HMXA(M)Q15/600
Certification :
ISO9001, CE
Place of Origin :
Made in China
MOQ :
1 Sets
Price :
USD 350.00-950.00/Sets
Payment Terms :
L/C, T/T, Western Union, D/P
Supply Ability :
10000 Sets/ per Year
Delivery Time :
Within 15-20 working days after receive 30% down payment
Packaging Details :
Standard Packing
Material :
SS304/316
Voltage :
380V/220V/400V, Customized
Power(W) :
2.2KW
Dimension(L*W*H): :
1950*700*900(mm)
Type :
Hydraulic Filter Press
Function :
Liquid Solid Separation,Dewatering
Filter Pressure :
≥0.8MPa
Application :
Beverage/Food/Beer/Pharmacy/Fine Chemical
Filter Area :
15-40M2
Material of bag :
PP
Dimension(L*W*H) :
2220*10*3700 mm
Cake Thickness :
30mm
Weight :
1854kg
Warranty :
1 Year
Description

High Efficient Easy Operation Stainless Steel Single Bag Filter Machine

Product Application

The filter bag is supported by the stainless steel mesh inside. The liquid flows into the chamber via inlet, and go through the filter bag. The impurities will be blocked into the filter bag. The filter bag can be reused repeatedly after washing or cleaning and it is easy to change the bag. The filter is features of no material consumption and low operation cost.

Application: Chemical industry, pharmacy, automobile industry, light industry, food industry, electroplating industry, etc.

2.2KW Power Stainless Steel Bag Filter Housing Single Bag Filter Machine2.2KW Power Stainless Steel Bag Filter Housing Single Bag Filter Machine2.2KW Power Stainless Steel Bag Filter Housing Single Bag Filter Machine

Advantages

1) High capacity, small size

2) Easy to replace the filter bag, no need clean and labor saving

3) After cleaning the filter bag can be used repeatedly to save cost

4) Lower leakage risk ensures high quality

5) Wide application, flexible use, various installation model for choice

6) High working pressure, low pressure loss, low operation cost and energy saving

Technical Data

Model
Filter area
(m2)
Plate Size(mm)
Filter chamber volume(L)
Plate Qty
(pcs)
Cake Thickness(mm)
Filtration Pressure
(MPa)
XA(M)Q15/630
15
700*700
226
18
30
<=0.6
XA(M)Q20/630
20
297
24
XA(M)Q30/630
30
452
37
XA(M)Q40/630
40
595
49
Model
Weight(kg)
Dimensions L*W*H(mm)
Foundation Size(mm)
L
B
D
H
XA(M)Q15/630
1257
2250*1080*1060
1870
560
910
700
XA(M)Q20/630
1347
2550*1080*1060
2170
XA(M)Q30/630
1693
3200*1080*1060
2820
XA(M)Q40/630
2193
3900*1080*1060
3520

Model XA(M)Y12/450-30U
Filter Area(m2) 12
Plate Size(mm) 450*450
Cake Thickness(mm) 30
Filter Chamber Volume(L) 182
Plate Qty(pcs) 29
Filtration Pressure(MPa) ≥0.6
Motor Power(Kw) 2.2
Weight(kg) 980
Dimensions L*W*H(mm) 2630*800*900
Foundation Size L/B/D/H(mm) 2280/300/800/650/450

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Maintenance, warranty.

Chengdu Hinming Environmental Protection Co., Ltd is a professional equipment manufacturing enterprises , specialized in design ,manufacture and sales of various filtration equipment as well as comprehensive filtration solutions and projects. We have a sound quality assurance system and advanced testing equipment ,can be from raw material into the factory warehousing , processing , assembly , to the whole machine factory supervision and control throughout the process . we have the high-class R&D personnel , experienced workers and high qualified sales team , we are devoting to provide best products for our clients

RFQ:

Q1: What is the Warranty for the machines?

A1: 12 months for free.

Q2: When can I get the price?

A2: Within 24 hours, if urgent, please directly call us.

Q3: Whether the machine price can be more discount?

A3: In general, our MOQ is 1set with very reasonable price, but if large order, we also can apply to our Manager to appropriately give you a little discount.

Q4: How to ask quotation?

A4: Please directly tell us which item you are interested in, or note us what tpye of materials, and how many tons of materials you want to treat per day or per hour, then we will send you quotation as soon as we can.

Q5: How long will it take to receive my products?

A5: As a general rule, it will take one 15-30 days for us to produce.
