ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter
ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter
Specifications
Brand Name :
XinMing
Model Number :
XA(M)Y80/870-30U
Certification :
CE，SGS，ISO9001
Place of Origin :
Made in China
MOQ :
1 Sets
Price :
Negotiation
Payment Terms :
T/T, Western Union, D/P
Supply Ability :
10000 Sets/Per Year
Delivery Time :
Within 15-25 working days after receive 30% deposit
Packaging Details :
Filter press main structure covered with Pearl cotton, spare parts in wooden cases
Product Name :
ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter
Description :
Liquid, solid separation of Ceramic Sludge
Application :
Ceramic sludge treatment
Type :
Automatic Filter Press
Cake Thickness :
30mm
Power(W) :
2.2KW
Dimension(L*W*H): :
5430*1200*1300(mm)
OEM :
OEM
Location :
Sichuan，China
The delivery speed :
AS FAR AS Possible
Description

ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter

Ceramic Sludge Treatment Press Filter Description
The ceramic sludge is pumped into the filter press for hydraulic compaction, and the undercurrent flows out of the extruded clean water. The sludge remains in the plate, relaxes the machine, and the sludge falls into a cake shape into the bottom to facilitate one-time transportation and treatment of the sludge. Quick and easy.
The filter press consists of a frame, a filter plate, a filter press system (manual, mechanical or hydraulic), and an electric control cabinet.
The frame is composed of a base, a push plate and a beam, and supports the compaction device and the filter plate.
The filter plate is installed on the beam between the tail plate and the push plate, and a filter cloth is sandwiched in the middle.
During work, a pressing device (cylinder piston rod or screw) drives the push plate to press the filter plate and filter cloth between the push plate and the tail plate. A filter chamber is formed between the filter plates, and the material enters the filter chamber through the feed port on the tail plate. The solid particles are trapped in the filter chamber to form a cake, while the liquid is discharged from the tail plate. Similarly, in order to dry the pressed cake, compressed air may be introduced through the washing port.
Technical Data
Model
 XA(M)Y80/870-30U
Filter Area(m2)
 80
Plate Size(mm)
870*870
Cake Thickness(mm)
30
Filter Chamber Volume(L)
 1210
Plate Qty(pcs)
 62
Filtration Pressure(MPa)
≥0.6
Motor Power(Kw)
 2.2
Weight(kg)
 4561
Dimensions L*W*H(mm)
5430*1200*1300
Foundation Size L/B/D/H(mm)
4610/600/1270/835/480
WHY CHOOSE US
ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter

How to work:

ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter

Factory Show
ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter
Customer display
ChengDu XinMing Ceramic Sludge Hydraulic Automatic Press Press Filter

FAQ

Q: how do I pay?
A: both t/t and l/c are acceptable. We would appreciate it.
Q: when will it be shipped?
A: it depends on the quantity ordered. It is usually delivered within 2-3 weeks.
Q: how is the product packaged?
We use standard packing. If you have special packing requirements, we will pack as required, but the cost will be paid by the customer.
Q: how do I install equipment when I arrive at my destination?
We will provide you with details. If necessary, we will send technicians to help you. However, visa fees, air tickets and accommodation will be paid by the buyer.
