304 316 Stainless Steel Ultra Fine Wire Mesh For Food Processing Industry

Specifications

Brand Name :

BJPFM

Model Number :

PFM - Stainless Steel Screen Printing Mesh

Certification :

SGS

Place of Origin :

China

MOQ :

1 Square Meters

Price :

Through consultation

Payment Terms :

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability :

5000 Square Meter/Square Meters per Month

Delivery Time :

7-10 work days

Packaging Details :

Moistureproof paper inside ,wooden cases outside and the plastic cloth filled in the middle

Material :

Ultra Fine Stainless Steel 304 304N 316 316L, etc

Weave type :

Plain

Wire diameter :

0.018-0.02mm

Thickness :

0.05 to 0.3mm

Mesh count :

3-400mesh

Mesh Opening :

0.022 to 23.37mm

Width :

0.6-1.5m

Application :

Screen Printing Industry

Length :

30m/roll 50m/roll or as your request

Feature :

Heat Resistance, High Tension Low Elongation, Corrosion Resisting, Long Life

Description

Plain Woven Ultra Fine 304 316 Stainless Steel Wire Silk Screen Printing Mesh

Name: 304 316 Stainless Steel Ultra Fine Wire Mesh For Food Processing Industry
Brand: BJPFM
Price: 1 USD

1. Stainless Steel Wire Silk Screen Printing Mesh Description

Material: Stainless Steel 304 304N 316 316L, etc;

Weave: Plain weave

Wire diameter: 0.018-0.02mm

Mesh/inch: 3-400mesh

Aperture: 0.022 to 23.37mm

Thickness: 0.05 to 0.3mm

Hole shape: square

Open area: 39.4%

Length: 30m/roll 50m/roll or as your request

Width: 0.6-1.5m

304 316 Stainless Steel Ultra Fine Wire Mesh For Food Processing Industry

2. Stainless Steel Wire Silk Screen Printing Mesh Features

High tension. Much higher tension than common polyester mesh and this property is very stable;0
Super Precision: Uniform wire diameter and aperture with an extremely low difference;
Low Precision: Very small elongation of wire mesh at high tension;
High Flexibility: The wire mesh will not lose elasticity at extreme tension;
High Corrosion Resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber;
Non-electrostatic: To avoid the effects of non-electrostatic for printing and ensure the safety of printing;
Good Heat-melting Resistance: Special features of stainless steel wire mesh.Suitable for heat-melting ink;
Good Solvent Resistance: To avoid the effects of any solvents to wire mesh and to ensure the safety of printing.

3. Stainless Steel Wire Silk Screen Printing Mesh Specification

Mesh/Inch	Wire Diameter (μm)	Aperture(μm)	Open Area (%)	Thickness(μm)	Theoretical Ink (cm3/m2)
40	160	475	56.0	300-320	179.1
60	120	303	51.3	230-245	123.21
80	50	268	71.0	95-100	78.0
80	90	228	52.0	175-180	103.0
80	120	198	39.0	235-245	92.9
100	100	154	36.8	195-205	77.2
120	80	132	39.0	155-165	65.8
150	60	109	41.7	115-124	50.0
165	35	119	60.0	70-75	48.0
165	45	109	50.1	88-93	45.1
165	50	104	45.6	97-105	45.6
180	45	96	46.4	88-93	41.5
