Copper Flexible Cable Shield 1000V PVC Insulation , Multi Core Electrical Cable
Copper Flexible Cable Shield 1000V PVC Insulation , Multi Core Electrical Cable
Copper Flexible Cable Shield 1000V PVC Insulation , Multi Core Electrical Cable
Copper Flexible Cable Shield 1000V PVC Insulation , Multi Core Electrical Cable
Copper Flexible Cable Shield 1000V PVC Insulation , Multi Core Electrical Cable
Copper Flexible Cable Shield 1000V PVC Insulation , Multi Core Electrical Cable
Specifications
Brand Name :
HWATEK
Model Number :
Flexible Cable,meter marking, oil resistant,UV Resistant, Shield,600V, PVC jacketed
Certification :
UL,CUL, CE,ROHS, REACH
MOQ :
6.1KM
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
2-3W
Packaging Details :
carton/pallet
Product Name :
Flexible Cable,meter marking, oil resistant,UV Resistant, Shield,600V, PVC jacketed
Size :
40AWG MIN
Conductor :
stranded, tinned or bare copper
Core Number :
Multiple-core
Standard :
UL758 AWM STYLE 2586 ,UL1581, UL2556, IEC60228 CL5
Insulation material :
PVC,PP,SRPVC,TPE, TPEE
Shield material :
bare or tinned copper braid or Spiral and AL-mylar
Sheath material :
PVC
Application :
For fixed installation or flexible application, with free movements without forcing which do not constantly recur and without tensile stress, for high mechanical strain
Rated Voltage :
1000V
Temperature :
-40℃-105℃
Flame :
VW-1,FT1,FT2,IEC60332-1-3
Free Sample :
YES
Description

Flexible Cable,meter marking, oil resistant,UV Resistant, Shield,1000V, PVC jacketed.

Construction

Conductor : stranded, tinned or bare copper
Insulation: PVC,PP,SRPVC,TPE, TPEE

Shield or Braid: bare or tinned copper braid or Spiral and AL-mylar

Jacket:PVC

Standards
International: UL758 AWM STYLE 2586 ,UL1581, UL2556, IEC60228 CL5

RoHS,REACH Compliant,

Technical data
Rated voltage:1000V

Rated Temperature:-40℃-105℃

Flame: VW-1, FT1, FT2,IEC60332-1-3

Voltage withstand test:AC 3.5kV/1min

Properties

Effectively resist electromaganetic interference

Excellent insulation performance

Extensively oil resistant

Flexible

LOW Temperature

UV resistant

High voltage

Specifications

Certificates

UL, CUL, CE

Packing and Shipping

  1. The cargo could be packaged as Hwatek’s standard requirement if client no special request, such as carton, wooden pallet or wooden case;
  2. If client put forward special packing requirements, Hwatek will specialize in custom materials and charge some fees;
  3. Hwatek’ll pack the cargo according to the transportation requirements strictly, including size, weight and safety;
  4. The cargo, manufacturer, packing details will be labeled on the outer packing;
  5. About transportation agent, Hwatek will give priority to customers' advice. If not, we can come up with some proposals and choose good and affordable agents for clients reference;
  6. Shipping term, It depends on the value of the goods and the will of the customer.
