GLONASS GPS Four Axis Aerial Drone Aerial Photography Ambarella A12 SONY CMOS Sensor
GLONASS GPS Four Axis Aerial Drone Aerial Photography Ambarella A12 SONY CMOS Sensor
GLONASS GPS Four Axis Aerial Drone Aerial Photography Ambarella A12 SONY CMOS Sensor
GLONASS GPS Four Axis Aerial Drone Aerial Photography Ambarella A12 SONY CMOS Sensor
Specifications
Brand Name :
NLD
Model Number :
NTA-CFLY
Certification :
ISO9001 CE FCC
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T, D/P, D/A
Supply Ability :
100sets/month.
Delivery Time :
15~25 days
Packaging Details :
Box
Type :
NTA-CFLY Aerial Camera Drones
Size(Fold) :
170*108*74mm(L*W*H)
Size(Unfold) :
180*255*74mm(L*W*H)
Wheelbase :
280mm
Weight :
515g
Max Service Ceiling Above Sea :
5000m
Description

NTA-CFLY Aerial Camera Drones With Ambarella A12 SONY CMOS Sensor

Model NTA-CFLY
Aircraft
Size(Unfold) 180*255*74mm(L*W*H)

Size(Fold)

170*108*74mm(L*W*H)
Wheelbase 280mm
Weight 515g
Max Descent Speed Clam mode: 1.5m/s
Normal mode: 1.5m/s
Sport mode: 2m/s
Max Ascent Speed

Clam mode: 2m/s
Normal mode: 2m/s
Sport mode: 5m/s
Max Speed Clam mode: 5m/s

Normal mode: 10m/s

Sport mode: 19m/s
Max Service Ceiling Above Sea 5000m
Operating Temperature Range 0℃-40℃
Max Fight Time 35mins
Maximum Flight Height 120m(Maxumum 500m(Need to change setting on app))
Satellite Positioning Systems GPS/GLONASS
Hover Accuracy Range

Vertiacl: +/-0.5m±0.2m(ultrasonic system, optical flow system works)
Horizonal: +/-1.5m±0.3m(ultrasonic system, optical flow system works)
Camera (Sensor SONY CMOS)
Sensor Ambarella A12, SONY CMOS
Video Recording Resolution 3840*2160
Supported File Systems FAT32(<=32GB)/exFAT(>32GB)
Operating Temperature Range 0℃-40℃
Image Size 5120*3840(20MP)
Maximum Video Bit 60Mbps
Supported SD Cards Micro SDTM Max capacity: 128GB, UHS-I Speed Grade 3 rating required
Shooting mode Single shot
Video MP4
Photo JPEG
3-Axis Gimbal (Fixed Height 3-Axis Micro Gimbal)
Controllable Pitch: -90°-0°
Stabilization
  • Pitch: +30/-120°
  • Roll: ±35°
  • Yaw: ±30°
Ultrasonic altitude system
Operating Except for surface of water or ground of absorbing material(such as thick carpet)
Altitude Range 0.2-4.5m
Velocity Range ≤3m/s
APP
Mobile APP C-Fly 2
Aerial Photography mode dronie, rocket, circle, helix
FPV Transmission Distance 5000m
Required Operating Systems Andrio 5.0 above, ISO 9.0 above
Live View Quality 720P
Optical flow system
Velocity Range ≤1.5m/s at 6.6 ft (2m) above ground
Altitude Range 0.2-4.5m
Operating Environment Surface with clear pattern and adequate lighting(lux>15)
Charger
Output 4.35V 0.7A*3
Rated Power 10W
Input 5V 2A(recommend)
Battery
Capacity 3100mAh
Net Weight 196g
Voltage 11.4V
Charging Temperature Range 0℃-40℃
Max charging power 35W
Battery Type LiPo 3S
Charge time <5h(with 5V 2A adapter)
Energy 35.34Wh
Remote Controller
Transmitter Power(EIRP) CE: ≤14dBm
SRRC: ≤20dBm
FCC: ≤23dBm
Operating Frequency 5.8GHz
Capacity 2600mAh
Battery Power 9.62Wh
Maximun Charge Power 5W
Battery Capacity(built-in) 3.7V
Max Transmission Distance 5000m
Operating Temperature Range 0℃-40℃
Operating Current/Voltage 500mA @ 3.7V
Charge USB
Battery Type LiPo 18650 1S
Charge Time <3h(with 5V 2A adapter)
Supported Mobile Device Size Thickness Supported: 6.5-8.5mm
