20L Hybrid Agriculture Spraying Drone Two Stroke Gasoline Engine FCC
20L Hybrid Agriculture Spraying Drone Two Stroke Gasoline Engine FCC
20L Hybrid Agriculture Spraying Drone Two Stroke Gasoline Engine FCC
20L Hybrid Agriculture Spraying Drone Two Stroke Gasoline Engine FCC
Specifications
Brand Name :
NLD
Model Number :
NLA-GB20
Certification :
ISO9001 CE FCC
Place of Origin :
China
MOQ :
1set
Price :
Negotible
Payment Terms :
L/C, T/T, D/P, D/A
Supply Ability :
100sets/month
Delivery Time :
20days
Packaging Details :
Aluminum Box
Name :
Hybrid Drone
Use :
Agriculture
Power system :
hybrid system
Pesticide tank capacity :
20L
Endurance :
Max 120minutes
Max take-off :
57kgs
Description

20L Hybrid Agriculture Spraying Drone Max Endurance 120 Min 130CC Two-stroke Gasoline Engine Take-off 57kgs

20L Hybrid Agriculture Spraying Drone Two Stroke Gasoline Engine FCC

Comparison of advantages

Gasoline Battery Hybrid Power Pure lithium battery system
Loading Gasoline energy density as high as 12 KWH/KG, with strong engine(power:weight＞1), its weight consumes less energy, so more energy allocation to more load.

Lithium battery energy density can only be reached 0.2KWH/KG, its weight consumes more energy, so less energy allocation to less load.
Endurance The energy density of gasoline is high. When replace part of the load to gasoline can greatly prolong the range, and is not affected by low temperature. The energy density of Lithium battery is low.Its weight consumes more energy, so less energy allocation to less range. Lithium battery loss much energy at low temperature.

Performance parameter

NLA-GB16 NLA-GB20 NLA-GB50 NLA-GB65
Rotor 4 6 6 6
Pesticide tank capacity 16L 20L 50L 65L
Max take-off weight 45kgs 57kgs 113kgs 160kgs
Endurance 15~120minutes
Power system 1set 7kw 1set 7kw 2sets 7kw 3sets 7kw
Fuel oil 92 # gasoline+oil blends(40:1)
Fuel consumption 6L/h 6L/h 12L/h 18L/h
Expanded size 1400x1400x700mm 1850x1850x700mm 2600x2240x1000mm 3100x2700x1000mm
Folded size 900x800x700mm 1150x880x700mm 1150x1300x1000mm 1700x1400x1000mm
Work efficiency 16.5acre/h 24.7acre/h 49.4acre/h 65.9acre/h

APP Ground Workstation

20L Hybrid Agriculture Spraying Drone Two Stroke Gasoline Engine FCC

1. Android mobile phone ground workstation, Control and adjust drone’s flying parameter, provide google map, check FPV video.

2. Support hand held GPS dot device,RTK dot device,Drone GPS dot and Map for choosing, set up Automatic, semi-automatic AB working mode, flying height, spray mode, flight line spacing, flying speed, Terrain following, automatic obstacle avoidance, course adjustment, fail-sail back.

3. Query job record, flight time, spray width, dose etc.

Gasoline Battery Hybrid Power

Output voltage

DC51.8V (14S LI-OH battery)

Maximum output power

7KW

Battery

14S LI-ION 5500MAH 30C

Charging current

30A

Engine

Two cylinder two stroke 130CC engine

Engine speed

4000RMP~7500RPM

Fuel specifications

92 # gasoline+oil blends(40:1)

Fuel consumption

7L/H(7KW Run continuously)

Size

336*280*240MM

Weight

10KG(Including host, control circuit and water tank, excluding oil tank)

Start launch

Built-in electric

Control way

Intelligent frequency conversion

Working temperature

-10℃~50℃
