Pesticides Tank 26L 5000m Agriculture Spraying Drone Quick Pluggable
Pesticides Tank 26L 5000m Agriculture Spraying Drone Quick Pluggable
Pesticides Tank 26L 5000m Agriculture Spraying Drone Quick Pluggable
Pesticides Tank 26L 5000m Agriculture Spraying Drone Quick Pluggable
Specifications
Brand Name :
NLD
Model Number :
NLB-626
Certification :
ISO9001 CE FCC
Place of Origin :
China
MOQ :
1set
Price :
Negotible
Supply Ability :
100sets/month
Delivery Time :
20days
Packaging Details :
Aluminum Box
Name :
Sprayer drone in agriculture
Capacity :
26L
Psticides tank :
26L Pluggable
Battery :
14S Battery Pluggable
Number of nozzles :
8 nozzles
Work time :
15~20min with payload
Description

New Style 6 Rotors 26L Sprayer Drone Pesticides Tank Quick Pluggable Easy Operation in Agriculture

Quick details:

Pesticide tank pluggable;

Lithium battery pluggable;

Quick disassembly easy operation;

Work method app ground station.

Pesticides Tank 26L 5000m Agriculture Spraying Drone Quick Pluggable

Specification:

Model NLB420 NLB620 NLB626 NLB630
Rotor 4 6 6
Tank type Pluggable Pluggable Pluggable
Pesticide Tank Capacity 20L 26L 30L
Battery type Pluggable Pluggable Pluggable
Battery 14S/22000mAh 14S/25000mAh 14S/28000mAh
Take-off Capacity 42kg 63kg 63kg

Hovering accuracy

horizontal

 +/- 1.5m +/- 1.5m +/- 1.5m

Hovering accuracy

vertical

 +/- 0.5m +/- 0.5m +/- 0.5m
Wind resistance 4～5 4～5 4～5
Motor 4*100KV 6*100KV 6*100KV
Electronic Speed Control 150A 150A 150A
Motor applicable temperature -20～50 -20～50 -20～50
Foldable propeller 3612 3612 3612
Frame type Foldable Foldable Foldable
Folded Size 1150*600*700mm 1150*600*700mm 1150*600*700mm
Flying Speed 0~10m/s 0~10m/s 0~10m/s
Flying Time (with payload) 15~20min 15~20min 15~20min
Flying distance 5000m 5000m 5000m
Working distance 2km 2km 2km
FPV Camera Camera Camera Camera
Spray Width 3.5~4m 3.5~4m 3.5~4m
Spray Flow 1.2~2L/min 1.2~2L/min 1.2~2L/min
Spray Efficiency 1500~2400sqm/min 1500~2400sqm/min 1500~2400sqm/min
Wheelbase 2029mm 2018mm 2018mm
RTK centimeter positioning Optional Optional Optional
Terrain following radar Optional Optional Optional
Obstacle avoidance radar Optional Optional Optional


App Ground workstation

Pesticides Tank 26L 5000m Agriculture Spraying Drone Quick Pluggable

1. 1080P HD image transmission, 10km distance;

2. 5.5" high brightness dispaly, high definition;

3. Android system with ground workstation, control and adjust the flying parameter;

4. Provide google map, check FPV video;

5. Support hand held GPS dot device, and RTK dot device;

6. High performance lithiium battery, 6 hours long life;

7. Setup atuomatic or semi-automatic AB working mode, adjust the flying height, spray mode, spray speed;

8. Support automatic fail-sail back, job record, flight time, flight area data record.

Centimeter level precision positoning system (optional)

1. High precision navigation and positioning system;

2. Real time dynamic differential technology to improve the three dimensional positioning accuracy from meters to centimeters;

3. Strong anti-magnetic interference;

4. Powerful multi-path effect and interference suppression technology;

5. Dual antennas wth high precision orientation;

6. High sensitivity, stable and reliable.
