R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval
Specifications
Brand Name :
CBFI
Model Number :
CV3000
Certification :
CE, ISO, BV, SGS, SONCAP
Place of Origin :
China, Guangzhou
MOQ :
1 set
Price :
USD 1-100000 per set
Payment Terms :
T/T, , Western Union, In Cash
Supply Ability :
50 set per month
Delivery Time :
30 days
Packaging Details :
standard wooden case for the cube ice machine and the machine fittings
Compressor :
Germany brand
Cube Ice Size :
22mm*22mm*22mm / 29mm*29mm*22mm
Refrigerant :
R507 / R404a
Material :
Stainless Steel 304
Daily production Capacity :
1 ton to 20 tons
Water :
Pure Clean and Edible Water
cooling system :
water cooling and air cooling
Description

CBFI manufacturer Ice Cube Machine maker stainless steel 304 ​

CBFI Cube Ice Making Machine

Model

 Ice Making Capacity Compressor power Circulating Water Pump Capacity Cooling Water Pump Capacity Cooling Fan Capacity Machine Dimention Weight of Machine
No. Ton/24h KW KW KW KW W*H*L KG
CV1000 1.0 3.69 0.37 1.5 0.37 1200*1000*1600 800
CV2000 2.0 7.11 0.37 1.5 0.55 1630*1600*1686 1000
CV3000 3.0 9.68 0.37 2.2 0.75 1980*1630*1840 1200
CV5000 5.0 17.47 0.55 2.2 1.5 2890*1780*1840 1600
CV8000 8.0 28.52 1.1 4 1.5 4820*1780*1840 2500
CV10000 10.0 37.68 1.1 4 1.5 5730*1780*2000 3000
CV15000 15.0 52.41 1.65 5.5 2.2 8620*1780*2000 4500
CV20000 20.0 75.36 2.2 8 3 11460*1780*2100 6000

After- sales service:

(1) During 2 years after selling, maintenance and parts free of charge.

(2) We can provide 12 months warranty for our machine. During the warranty period, if your machine don’t work, you can send us pictures or video or call us about the fault. We will immediately mail you the solution to solve the problems within 24hours. If the part is broken for nonpersonal reason,we will replace one for free within guarantee period. But if beyond guarantee period, we will charge market price for the new parts.

Note:

1.The above information is on the basis of water-cooled condensing.

2.Size of machine is before installation. It didn’t included the size of cooling tower, which is usually installed outside the room.

3.Machine running condition:

water temperature:23℃,

evaporate temperature:-12℃,

condensing temperature 40℃,

reference valve under 50Hz power supply.

Real production of machine will have a little change according to change of water temperature and ambient temperature.

R507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE ApprovalR507 / R404a Refrigerant Ice Cube Maker Machine Stainless Steel 304 CE Approval

Application:

Cube ice machines are widely used in hotels, restaurants, bars, fastfood shops, supermarkets and cold

drink shops,et. Icesource ice machine are highly efficient, energy saving,safe and environmentally friendly

and quickly becoming the most popupar choice for client around the world.

the usage of cube ice:
