Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant
Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant
Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant
Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant
Specifications
Brand Name :
CBFI
Model Number :
BF500-BF30000
Certification :
CE, ISO
Place of Origin :
Guangzhou,China
MOQ :
1 set
Price :
$100,000
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
30 sets per month
Delivery Time :
30 days after payment
Packaging Details :
International Standard Wooden Case
Compressor :
Germany /Taiwan Hanbell
Cooling way :
Water Cooling& Air Cooling
Thickness of ice :
1.0 -2.5mm
Length of ice :
25-45mm
daily capacity :
10 ton
Refrigerant :
R507 or R404a
Packing :
International standard wooden case
Material of evaporator :
304 stainless steel or 316 stainless steel
Description

CBFI Compressor design customized energy saving 10 tons flake ice machine
1. Basic details for flake ice maker machine

1. Ice thickness: 1.5mm to 2.2mm
2. Daily capacity: 1 tons,2 tons,3tons,5 tons …60 tons.
3. Flake ice machine type: use fresh water or sea water , use on land or on vessel.
Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant

2. 10 tons flake ice machine picture

ModelIce Making CapacityCapacity of RefrigerationMachine DimensionWeight of Machine
No.Ton/24hKWL*W*H(mm)KG
BF5000.53.751220*900*1000160
BF100018.851300*960*1200210
BF2000217.841500*1200*1350360
BF3000324.151800*1250*14001000
BF5000535.12100*1250*15001100
BF6000645.852500*2040*22001100
BF8000852.72100*1250*15001300
BF100001076.12300*1750*17401500
BF1500015110.93200*2100*20003200
BF20000201513400*2200*25604200
BF30000301803800*2300*25605000
BF3500035214.24500*2300*28006000
BF4000040226.17800*2100*30007500
BF5000050268.15000*2300*300010000
BF6000060278.45500*2300*320012000


3. Flake ice application:
Flake ice widely used in: Supermarket, food processing enterprises, chain catering, concrete mixing plant, chemical plant.
Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant
Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant
4. Flake ice machine specification








Working Conditions

Refrigerant

R507/ R404a/R507

Cooling way

Water cooling／Air cooling

Machine size

2200*1900*1750mm

Ambient temp.

+50 ℃

Supply water temp

20 ℃

Evaporating temp.

-20 ℃

Condenser temp.

+40 ℃

Relative humidity

85 %

Noise

55dB



Compressor

Brand Name

Taiwan Hanbell

Product Model

RC2-180B-Z

Power

34.1KW

Refrigerating Capacity

75.9 KW







Other electric components

Brand Name

CBFI

Power of Cooling Water Pump

0.55 KW

Power of Reducer

0.37 KW

Cooling Water Consumption

0.05 m3/h

Power of Condensing water pump

3.7 KW

Power of condensing air cooling fan

0.75KW

Customized 10 Tons Flake Ice Machine CBFI Compressor R507 Refrigerant


5. Our Service:
* Warranty: One year.
* Manual Book: Detail instruction book with clear drawing will be provided to tell you how to install and operate the machine.
* If customer's technicians come to Guangzhou and visit our factory, we can train the customer's technicians to operate and install machines.
* It is possible that customers need our technicians to install and train customers operating machines in their country. We have technicians who have been to many different countries to work.
* If you are interested in our products, please contact us. We would be very glad to provide professional service for you.
