Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
Specifications
Brand Name :
PAC
Model Number :
P-392TB
Certification :
CE, FCC, ROHS
Place of Origin :
Made in China
MOQ :
1pc
Price :
Negotiation
Payment Terms :
TT, PayPal, Western Union
Supply Ability :
3000pcs per month
Delivery Time :
1-2 weeks
Packaging Details :
Inner box plus outer carton
language :
any
Braille :
optional
mount :
panel mount
trackball :
built-in
touchpad :
optional
application :
kiosk or other industry
key :
67
silicone :
for sealing
Description

Industrial Panel Mount Keyboard With Trackball Mouse And 67 Key

Trackball Keyboard Features:

1. 67 key Braille dots EMC keyboard with 38.mm optical trackball,

2. The keyboard is with rear panel mount solution

3. With touchpad keyboard optional

4. The keyboard is with S304 stainless steel for the front panel and the buttons

5. With USB or PS2 interface, plug and play, no need driver

6. Customized function keys or combination keys upon request

7. Different language layout is available, please see below table

8. With high quality black titanium optional upon reqeust

9. IP65 grade trackball keyboard for harsh outdoor application

10. Keyboard front panel size 392 x 110mm

11. With the customs industrial keyboard size optional upon request

12. PN: P-392TB data sheet download: P-392TB data sheet.pdf

Keyboard Mechanical & Electrical Data:

Trackball Size: 38.mm trackball
Power Supply: DC5V±5%
Working Current: <150mA
Interface: USB or PS2 Interface with standard 2.5m cable, or the customs length like 2.0m or 1m
Button Size: 14x14x4.5mm, 14x28*x4.5mm, 14x100x4.5mm
Key Operation Force: 280g±20g
Durability: ≥5 Million
Keyboard Front Panel: 392x110mm or it is possible to make the customs size
Operation Temperature: -10℃~55℃ (Relative humidity 20%~85% / Atmospheric pressure 60~106Kpa)
Storage Temperature: -30℃~85℃ (Relative humidity5%~90%/ Atmospheric pressure60~106Kpa)
Supporting Systems: Window XP, Window 7, Window 8, Linux, Ubuntu, Android etc.

Trackball Keyboard Layout Options:

German industrial keyboard Italian industrial keyboard Spanish industrial keyboard
French industrial keyboard Nordic industrial keyboard UK industrial keyboard
Russian industrial keyboard Hebrew industrial keyboard Korean industrial keyboard
Japanese industrial keyboard Abraian industrial keyboard Thai industrial keyboard etc.

Metal Keyboard With Trackball Application:

  • Kiosk machines where there is no or semi-supervised positions of varied access applications
  • Internet terminals and information machine at places without supervision
  • Shopping malls, hotels, airports, railway stations and other public areas
  • Vending machines,
  • Petrol stations,
  • Cash machines
  • Bank machines
  • Other public places
  • Other industrial fileds
  • Panel Mount Industrial Keyboard With Trackball Mouse 67 Keys Optional Braille
