1000W 1500W Stainless Steel Automatic Welding Machine Raycus / IPG Laser Source Brand
1000W 1500W Stainless Steel Automatic Welding Machine Raycus / IPG Laser Source Brand
Specifications
Brand Name :
Domainlaser
Model Number :
CY-W1000FS/CY-W1500FS
Certification :
CE&FDA
Place of Origin :
China
MOQ :
1 Unit
Payment Terms :
L/C, D/P, D/A, T/T, Western Union, MoneyGram
Supply Ability :
200units/per month
Delivery Time :
3-5 working days
Packaging Details :
Wodden packages
Welding Depth :
3mm
Laser Source Brand :
Raycus/IPG
Application :
Metal Stainless Steel, Aluminum Welding
Welding Thickness :
0.5-4mm
Power Supply :
220V/50HZ/60HZ
Width Adjustable :
0-4mm
Wavelength :
1070nm
Laser type :
Fiber laser
Laser Power :
1000watt/1500watt
Product Name :
1000W 1500W Fiber Handheld Laser Welding Machine
Warranty :
2 years
Description

1000W 1500W Handheld Fiber Laser Welding Machine for Aluminum Stainless Steel in Laser Welders

Hand-Held Wobble Laser Welding Head+System Solution

1. This welding head could be widely used in complex and irregular welding process such as cabinets, kitchen, staircase, shelf, gridiron, stainless steel door and window guardrail, distribution box, stainless steel furniture and other industries.
It's a perfect replacement of traditional argon arc welding, in welding thin stainless steel plate, iron plate, aluminum plate and other metal materials.
2. Smart internal design and interactive control system expan the tolerance range and welding width of the processing parts, and solve the disadvantage of minor laser welding spot, and provide better welding forming.
3. Light shape, Ergonomic design, advanced structure, and reliable performance ensure comfort grip and simple operation.
4. With multiple safety alarms, it auto locks light after removing the work piece, which is safe.
5. Nice welding seam, fast welding speed, no consumables, no welding marks, no discoloration, no later polish.
6. This head could be equipped with a variety of angular nozzles to meet the welding needs of different products.
Features

A, The energy, pulse width, frequency and light spot size can be adjusted in a large range to realize different welding effects.

B. Imported ceramic converging cavity. It is corrosion resistant and high temperature resistant with 8-10 years life span. The life of xenon lamp is more than 8 million times.

C. Most advanced light shielding system eliminates the irritation to eyes by laser during working.

D. Able to work for 24 hours continuously; stable performance; 10,000 hours free maintenance.

E. Human-based design accords with ergonomics, avoiding fatigue after long time working.

F. High speed, high efficiency, deep enough, slightly deformation, small heat effect area, high welding quality, pollution free, environmental friendly.

Applicable Materials:

Materials are extensive: cold work alloy steel, hot work alloy steel, nickel tool steel, steel alloy, high tenacity aluminum alloy, etc. Other metals like gold, silver, brass, aluminum-magnesium alloy, titanium, and platinum are also applicable.

Parameter
1) Type of interface: QBH
2) Lasting power: 1500W
3) Collimating focal length: 50mm
4) Protective amplitude surface: 0-4mm
5) Laser incidence mode: Coaxial
6) Laser wavelength range: 1070+20
7) Focus length: 80mm 120mm
8) Total weight: 1.36kg

Main Technical Parameters

L/N Characteristic Testing Condition Min Value Typical Value Max Value Unit
1 Power Voltage 210 220 230 V/AC
2 Power 100% Output 5.5 KW
CY-WF1000W
3 Working Temperature 0 40 ℃
4 Working Humidity 10 85 ℃
5 Cooling Way Water Cooling
6 Storage Temperature -10 60 %
7 Machine Dimension 1000W 1040*600*1190( L * W * H ) mm
8 Machine Weight 1000W 226±3 kg

Main Advantages

Laser welding is to irradiate a high energy density laser beam on two parts of the material, so that the local heating melt, and then cooling and solidification into one. Compared with traditional welding technology, laser welding has the following advantages:
1. Precise positioning
Optical fiber laser welding machine is equipped with CCD camera monitoring system, which is convenient to observe, and can precisely locate by spot in micro-welding.
2. Uniform weld spot
The spot energy distribution of optical fiber laser welding machine is uniform, and it has the best spot needed for welding characteristics.
3. Suitable for all kinds of weld's screams
Fiber laser welding machine adapts to all kinds of complex welds, spot welding of various devices, and welding seams of thin plates within 1mm. It has fast welding speed, large depth and small deformation.
4. Batch & Mass Production
Optical fiber laser welding machine can customize special automatic fixture to realize mass production of products.
5. Corrosion Resistance and High Temperature Resistance
Fiber laser welding machine uses ceramic concentrator, which can be welded at room temperature under special conditions, such as vacuum or through glass materials, and has simple equipment, corrosion resistance and high temperature.
