Specifications
Brand Name :
ITD/OEM
Model Number :
ITD08PPCT1HBJ2
Certification :
CE,FCC, RoHS Compliance
Place of Origin :
China
MOQ :
1PCS, No MOQ
Price :
TBA
Payment Terms :
T/T
Delivery Time :
10-15 Business days
Description

8'' Embedded Industrial LCD Rugged HD All-In-One Fanless Touchscreen PCs | High Brightness | Resistive | Panel Mount |

8'' Embedded Industrial LCD Rugged Monitor HD All In One Fanless Touchscreen PCs8'' Embedded Industrial LCD Rugged Monitor HD All In One Fanless Touchscreen PCs8'' Embedded Industrial LCD Rugged Monitor HD All In One Fanless Touchscreen PCs8'' Embedded Industrial LCD Rugged Monitor HD All In One Fanless Touchscreen PCs

ITD 8” ITD08PPCT1HBJ2 is panel mount high bright touch PCs provide OEMs with vast selection of technologies and solutions simplifying PLC, HMI and SCADA applications. These PCs feature Intel® Celeron™ Quad Core Processor J1900 2.0 GHz, in industrial-grade LCD flat panels with resistive touch technology and NEMA 4 IP65 front bezel optional designed for HMI display and visualization solutions. These HMI thin clients are designed for process manufacturing, discrete manufacturing, industrial automation, process control, building automation, access control, room reservation, room scheduling, and custom HMI applications.

FEATURES

▪ Flexible, reliable, and ruggedized for open platform HMI/SCADA

▪ Energy-efficient and fan-less HMI Systems

▪ Ruggedized levels of NEMA 12, NEMA 4, IP52, IP54, IP65 ratings for front panel

▪ Aluminum front bezel and steel chassis construction designed for harsh and industrial environments

▪ Flexible, easy configuration and integration

▪ CE, FCC, RoHS Compliance

OPTIONALS

•Anti-Glare / Anti-Reflective tempered glass

•SDD 64GB,128GB up to 521GB

•HDD 500GB up to 1TB

•Touch optional: Resistive, IR, PCAP

•Optical bonding

•DC24V, DC 9-36V

SPECIFICATION

System CPU Intel® Celeron J1900 2.0GHz Processor
Memory 2GB, 4GB optional
Chipset Inter Valley View SSA-Cunit
HDD 320GB SATA or 32GB SSD
LAN 1 x 10/100/1000Mbps Ethernet
Panel Cell Type/Glass Surface TFT LCD
Aspect Ratio/Size 8.4''
Active Area/Pixel Pitch 214 (H) X 178(V)/0.264mm
Native Resolution/Colors 800 x 600 /16.2M
Response TBrightness/Contrast 1000nits/700:1
Viewing Angle(Typical) 75/75/75/75
Light Source LED backlight with 50000hours’lifetime
Input / Output Serial Ports 2 x COM
USB Ports 4 X USB
HDMI Port 1 X HDMI
VGA Port 1 x VGA
LPT Slot N/A
Audio MIC-IN, LINE-OUT
Power Input Voltage External power supply with universal / Auto-Sensing, DC 12V
Operation/Power Saving 25W(Max)
Operating Temperature -10℃~60℃ (20~70℃ Optional)
Storage Temperature -20℃~70℃
Relative Humidity 10%~90% (non condensing)
Convenient Features Backlight adjustment, Plug & Play
Power External AC-to-12VDC power adapter with universal/Auto-Sensing
Power Consumption Operation/Power Saving: Below 15W
OS Support Windows 7/ 8/10, Windows Embedded, Linux, Win CE
Touch Panel Resistive touch panel
Key Control Power on/off with LED, Menu, Select, Adjustment(Right/Left)
