TFT Industrial All In One PC Touch Screen 7'' Linux Fanless Intel J1900/Z8350
TFT Industrial All In One PC Touch Screen 7'' Linux Fanless Intel J1900/Z8350
TFT Industrial All In One PC Touch Screen 7'' Linux Fanless Intel J1900/Z8350
TFT Industrial All In One PC Touch Screen 7'' Linux Fanless Intel J1900/Z8350
Specifications
Brand Name :
ITD/OEM
Model Number :
ITD07PPCT5KJ1
Certification :
CE/ROHS/FCC
Place of Origin :
China
MOQ :
1PCS
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
10000 unit per month
Delivery Time :
15 work days
Packaging Details :
Foam,gift box,master carton,wooden case,pallet
CPU :
Intel J1900 Quad Core 2.0Ghz, Intel Z8350 optional
Memory :
DRAM 2GB
Storage :
64G SSD max. 1TB
OS :
Windows 7/8/10, Linux
I/O :
2 x USB3.0,2 x USB2.0,1 X HDMI,1 x COM, 1 x DC, 1x RJ45
MTBF :
50000h
Operating Temperature :
-10~60℃
3G/4G :
Optional
Warranty :
1 Year for TFT panels and 2 Years for others
Power :
1 x DC 12V,, DC24, DC9-36V optional
GPS, PoE :
Optional
Aging Test :
48H
Housing Type :
Aluminum Frame, Steel Back Chassis
Price :
TBA
Description

mini touch panel pc 7inch industrial hmi touch panel linux fanless Intel J1900/Z8350

ITD 7” multi-touch screen HMI comfort panel PC is fully-integrated‚ multi capacitive touch screen combines high-performance Intel® Celeron™ Quad Core Processor J1900 2.0 GHz, and Projected Capacitive Touch (PCT or PCAP) Technology in industrial-grade LCD flat panels, with sleek and flat front surface industrial design. This PCT technology is a capacitance system that delivers sensitive and accurate 10 multi-touch interactive experiences. The ITD 8” multi-touch HMI comfort panel PC specifically suited for various interactive digital signage applications.

FEATURES

▪Easy-to-clean, true flat front surface without bezel

▪Flexible, reliable, and ruggedized touch screen computers for open platform HMI/SCADA

▪Ten independent touch points (with Windows 7/8, Android, Linux operating systems)

▪Eliminates dust and debris build-up at the edge and corners of the display

▪Provides improved power efficiency and reduced consumption

▪Responds to a light touch to activate response

▪Ruggedized levels of NEMA 12, NEMA 4, IP52, IP54, IP65 ratings

▪All steel and aluminum frame construction designed for harsh and industrial environments

▪CE, FCC, RoHS Compliance


Panel Cell Type/Glass Surface TFT
Size 7”
Aspect Ratio 16:9
Active Area 155.5(H) x 87.5(V)mm
Pixel Pitch 0.150 × 0.150mm
Native Resolution 1024 x 600
Colors 16.7M
Brightness 300cd/㎡
Contrast 800:1
Response Time 10/15ms
Viewing Angle(Typical) 85/85/85/85
Light Source LED Backlight with 50000Hours’Lifetime

SPECIFICATION

System CPU Intel® Celeron J1900 2.0GHz Processor
BIOS AMI
Chipset Intel VallVieW SSA‐Cunit
Memory 1xSO-DIMM, DDR3 1333MHz Memory, 2GB, Max.8GB
Graphic Chipset CPU integrated graphics HD and support 1080p
Storage 64GB SSD
LAN 1 x 10/100/1000Mbps Ethernet
Input / Output Serial Ports 1 x COM
USB Ports 4 X USB
VGA Port 1 x VGA
HDMI Port 1x HDMI Port
Audio Card

with Realtek ALC662

Line-Out/MIC IN
Power Input Voltage DC 12V
Operation/Power Saving 15W
Environment Considerations Operating Temperature -10~60℃
Storage Temperature -20~70℃
Relative Humidity 10%~90%
OS Support Windows 7/ Windows XP/ Windows 8/ Linux
Mounting Method VESA, side mounting brackets optional
Accessories Power cable, Motherboard CD driver, Screws
Order Information 7” Zero-Bezel Panel PC with PCAP Touch J1900/ITD07PPCT5KJ
7” Zero-Bezel Panel PC with Tempered Glass J1900/ITD07PPCG1KJ

Typical Application

Banking Automation

Gaming/Casino Systems

Self-Service Kiosks

Entertainment

Transport and Ticketing

In-Home Control Devices

Automation

Vehicle

Marine

Security

Customized Solutions
