LMS500HF05 5.0 inch Samsung LCD Panel , lcd display small 800 / 1 Contrast Ratio
LMS500HF05 5.0 inch Samsung LCD Panel , lcd display small 800 / 1 Contrast Ratio
LMS500HF05 5.0 inch Samsung LCD Panel , lcd display small 800 / 1 Contrast Ratio
LMS500HF05 5.0 inch Samsung LCD Panel , lcd display small 800 / 1 Contrast Ratio
Specifications
Brand Name :
Samsung LCD Panel
Model Number :
LMS500HF05
Certification :
ISO9001
Place of Origin :
Japan,Korea
MOQ :
1 piece
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
100 PCS PER DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Type :
a-Si TFT-LCD , Panel
Panel Size :
5.0 inch
Resolution :
480×272(RGB) , WQVGA
Display Mode :
VA, Normally Black, TMR
Contrast Ratio :
800 : 1 (Typ.)
Display Colors :
16.7M (8-bit)
Response Time :
17/15 (Typ.)(Tr/Td)
Viewing Angle :
80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Description

LMS500HF05 5.0 inch Samsung LCD Panel , lcd display small 800 / 1 Contrast Ratio

Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LSC550FJ03-W Samsung 55" 3840×2160
LSC490HN03-W Samsung 49" 1920×1080
LSC650FJ10-W Samsung 65" 3840×2160
LSC490HN04-W Samsung 49" 1920×1080
LSC400HM15-W Samsung 40" 1920×1080
LSM315HP02-M01 Samsung 31.5" 1920×1080

Pls contact to us for more stock information: salespm@nselectronic.com.hk

SAMSUNG SMD LMS500HF05 General Features

Panel Brand : SAMSUNG SMD
Panel Model : LMS500HF05
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 5.0 inch
Resolution : 480×272(RGB) , WQVGA
Display Mode : VA, Normally Black, TMR
Active Area : 110.88×62.832 mm
Contrast Ratio : 800 : 1 (Typ.)
Display Colors : 16.7M (8-bit)
Response Time : 17/15 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : WLED
Signal Interface : Parallel RGB (1 ch, 8-bit)
Input Voltage : 3.3V (Typ.)

We Can Do for You

• Long lasting product cycle for continuity thru all phases of project rollouts and servicing

• Easy-to-install console, Open Frame chassis-mount display

• Slim dimensions enable better enclosure designs

• Multiple mounting options (100mm VESA mount and side brackets)

• All steel construction provides rugged frame for public use environments

• Two independent touch points (with Windows 7 OS)

• Improved power efficiency and reduced consumption

• TUV, CE, UL, CUL, FCC-B, RoHS, and IPX1 approvals

Company Strength

1. ISO9001 certificated, Factory Direct Supplied

2. RoHS Compliant, Lead Free, Reach Compliant

3. Competitive Price and Short Lead-time

4. Professional Team with Rich Experiences in Design/Mfg/Quality Control

5. Small MOQ Support & Fast Response to Customers

6. Long Product Life Time

SAMSUNG SMD LMS500HF05 Mechanical Features

Panel Size : 5.0 inch
Dot Resolution : 480×272(RGB) (WQVGA)
Pixel Configuration : RGB Horizontal Stripe
Pixel Density : 109 PPI
Aspect Ratio : 16:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.231×0.077 mm (H×V)
Pixel Pitch : 0.231×0.231 mm (H×V)
Active Area : 110.88×62.832 mm (H×V)
Landscape or Portrait : Landscape type
Touch Panel : Embeded (4-wire Resistive, Film / Glass)
