A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution
A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution
A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution
A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution
Specifications
Brand Name :
Tianma LCD Displays
Model Number :
TM070RDH10-20
Certification :
ISO9001
Place of Origin :
Japan，Korea
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Resolution :
1024(RGB)×768 , XGA
Active Area :
141.312×105.984 mm
Outline :
154×119.2×4.8 mm
Viewing Angle :
80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Signal Interface :
LVDS (1 ch, 8-bit) , 40 pins
Lamp Type :
3S9P WLED Without Driver
Description

A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution

Our Advantages
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: PayPal, Western Union and T/T are preferred, so just tell us which is easier to you. Then we will send you our bank details. Or your requirements.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, Trade Manager or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 7~10 working days. For bulk orders, usually 15~20 working days and depends on your design.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship samples. For bulk orders, we support shipping by air or by sea.
Q6: Can you customize according to our designs and put our logo on the products?
A6: Yes, we support both standard and customized products and can put your logo on the products. Our experienced R&D team will support technical questions. ODM/OEM is welcome.

AUO A070XN01 V1 Mechanical Features

Panel Size : 7.0 inch
Dot Resolution : 1024(RGB)×768 (XGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 184 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.046×0.138 mm (H×V)
Pixel Pitch : 0.138×0.138 mm (H×V)
Weight : 180g
Surface : Antiglare (Haze 3%), Hard coating (3H) A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution
Active Area : 141.312×105.984 mm (H×V)
Bezel Area : 143.312×107.984 mm (H×V)
Outline Dimension : 154×119.2 mm (H×V)
Outline Depth : 4.5±0.3 mm
Holes & Brackets : Without
Landscape or Portrait : Landscape type
Touch Panel : Embeded (Projected Capacitive Touch)



AUO A070XN01 V1 Signal Interface

Signal Category : LVDS
Signal Class : LVDS (1 ch, 8-bit)
Input Voltage for Panel : 3.3/5.3/-5.3V (Typ.)(VDDIO/VDPA/VDNA)
Input Current for Panel : 17/10/10mA (Typ.)(IDDIO/IDPA/IDNA)
Panel Power Consumption : 170mA
Interface Type : FPC
Signal Interface : Brand Model Pin Pitch Pins Amount Configuration
0.5 mm 40 pins 1 pcs LVDS-40P1C8B-040A


Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
TM240160XCFWGRA Tianma 2.2" 240×160
TM128128F6CCWGWC1 Tianma 1.44" 128×128
TM12864G3CCWGWA-1 Tianma 2.4" 128×64
TM050XYSP02 Tianma 5.0" 540×960
TM050JYHN11-00 Tianma 5.0" 720×1280
TM055JYSP08 Tianma 5.5" 720×1280
TM040XYHP01 Tianma 4.0" 640×1136
TM055JYSP03 Tianma 5.5" 720×1280

Packing & Delivery for our LCD Screen Panel Replacements

1. Anti-static Bag Packing.
2. Anti-Shock Bubble Bag Packing
3. Foam and Hard Carton Packing
4. Picked up by forward and delivered by express services.
Details Pictures for A070XN01 V1:

A070XN01 V1 1024 ( RGB ) ×768 XGA lcd flat panel display high Resolution
