1600*1200 Flat Rectangle Display M201UN02 V3 AUO LCD Panel for20.1 inch without touch

Delivery Information:
Our professional testing team will test the LCD panels pcs by pcs, to make sure the LCD screen sent out are with good quality.
Shipping Method:
By Express: FedEx, DHL, EMS, TNT, UPS,
By Logistics: By air
Shipping Time:
From Monday to Saturday 8:00am-17:30pm
Shipping Address:
If by T/T, shipping address as communicate

Why Choose our company?

Our LCD module can ensure quantity of sale especial for the Hard-to-find LCD screen replacements.
Reliability test and full examination to ensure the high quality of the display.
Strictly ISO9001 quality management system.
Mature and Professional after-sale service.
Various cooperation experience with big brands, such as AUO, Chimei, Hitachi, Innolux, KOE, Tianma, LG, NEC, Samsung, Sharp, Optrex and more other TFT LCD Display brands.

Optical Features

Display Mode : P-MVA, Normally Black, Transmissive
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 700 : 1 (Typ.) (Transmissive)
Display Color : 16.7M (8-bit)
Color Gamut : 72% NTSC (CIE1931)
Response Time : 15/10 (Typ.)(Tr/Td)
Viewing Angle : 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : Symmetry
White color Chromaticity : Wx:0.313; Wy:0.329
White Variation : 1.25/1.33 (Typ./Max.)(9 points)

General Features

AU Optronics M201UN02 V3 Mechanical Features
Panel Size : 20.1 inch
Dot Resolution : 1600(RGB)×1200 (UXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 99 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.085×0.255 mm (H×V)
Pixel Pitch : 0.255×0.255 mm (H×V)
Weight : 3.00Kgs (Typ.)
Active Area : 408×306 mm (H×V)
Bezel Area : 412.0×310.0 mm (H×V)
Outline Dimension : 432×331.4 mm (H×V)
Outline Depth : 23.1 (Typ.) mm
Holes & Brackets : Side mounting holes (8-M3) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without

AU Optronics M201UN02 Series Model

We still have other LCD panel models and more in stock:
Sizes: 7.0, 8.9", 9.7", 10.0", 10.1", 10.2", 10.4", 11.1", 11.6", 12.1", 12.5", 13.1", 13.3", 14.0", 14.1", 14.5", 15.0" 15.4", 15.6", 16.0", 16.4", 17.0", 17.1", 17.3", 18.4"
Resolutions: XGA, WXGA, WXGA HD, , WXGA+, WXGA++, WSVGA, WUXGA, WUXGA+, WUXGA++, Full-HD
Backlight technologies: LED, SLIM LED, 1 CCFL, 2 CCFL

Brands: NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE and more.

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk
