CMO innolux touch screen N101L6 - L02 10.1 inch 222.72×125.28 mm Active Area
CMO innolux touch screen N101L6 - L02 10.1 inch 222.72×125.28 mm Active Area
CMO innolux touch screen N101L6 - L02 10.1 inch 222.72×125.28 mm Active Area
CMO innolux touch screen N101L6 - L02 10.1 inch 222.72×125.28 mm Active Area
Specifications
Brand Name :
CMO
Model Number :
N101L6-L02
Certification :
ISO9001
Place of Origin :
Japan,Korea
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Type :
a-Si TFT-LCD , Panel
Panel Size :
10.1 inch
Resolution :
1024(RGB)×600 , WSVGA
Outline :
235×143×5.2 mm
Shape Style :
Wedge (PCBA Bent, Depth ≥5.2mm)
Surface :
Glare (Haze 0%), Hard coating (3H)
Response Time :
3/7 (Typ.)(Tr/Td)
Viewing Angle :
45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)
Description

CMO innolux touch screen N101L6 - L02 10.1 inch 222.72×125.28 mm Active Area

CMO N101L6-L02 General Features

Panel Brand : CMO
Panel Model : N101L6-L02
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 10.1 inch
Resolution : 1024(RGB)×600 , WSVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 222.72×125.28 mm
Outline : 235×143×5.2 mm
Shape Style : Wedge (PCBA Bent, Depth ≥5.2mm)
Surface : Glare (Haze 0%), Hard coating (3H)
Brightness : 200 cd/m² (Typ.)
Contrast Ratio : 650:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 3/7 (Typ.)(Tr/Td)
Viewing Angle : 45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 9S2P WLED
Signal Interface : LVDS (1 ch, 6-bit) , 40 pins
Input Voltage : 3.3V (Typ.)

Our Service

• Long lasting product cycle for continuity thru all phases of project rollouts and servicing

• Easy-to-install console, Open Frame chassis-mount display

• Slim dimensions enable better enclosure designs

• Multiple mounting options (100mm VESA mount and side brackets)

• All steel construction provides rugged frame for public use environments

• Two independent touch points (with Windows 7 OS)

• Improved power efficiency and reduced consumption

• TUV, CE, UL, CUL, FCC-B, RoHS, and IPX1 approvals

Company Strength:

1. ISO9001 certificated, Factory Direct Supplied

2. RoHS Compliant, Lead Free, Reach Compliant

3. Competitive Price and Short Lead-time

4. Professional Team with Rich Experiences in Design/Mfg/Quality Control

5. Small MOQ Support & Fast Response to Customers

6. Long Product Life Time

CMO N101L6-L02 Optical Features

Display Mode : TN, Normally White, Transmissive
Brightness : 200 cd/m² (Typ.)
Contrast Ratio : 650 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Response Time : 3/7 (Typ.)(Tr/Td)
Viewing Angle : 45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : 6 o'clock
White color Chromaticity : Wx:0.313; Wy:0.329
White Variation : 1.25 (Max.)(5 points)

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
CLAG045LJ72 CPT 4.5" 480×854
CLAN050WD61 6XM CPT 5.0" 720×1280
CLAD015GC41 AX CPT 1.5" 240×240
CLAA090WK05XN CPT 9.0" 1280×720
CLAC080XA12LW CPT 8.0" 1024×768
CLAD015GB01 AX CPT 1.5" 240×240
CLAG045LG71 XX CPT 4.5" 480×854
CLAG045LH41 AXXA CPT 4.5" 480×854

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

Details Pictures for CMO Touch Panel N101L6-L02

CMO innolux touch screen N101L6 - L02 10.1 inch 222.72×125.28 mm Active Area
