LB043WQ1 - TD02 4.3 inch LG LCD Panel Display 95.04×53.856 mm Active Area
LB043WQ1 - TD02 4.3 inch LG LCD Panel Display 95.04×53.856 mm Active Area
Specifications
Brand Name :
LG LCD Panel
Model Number :
LB043WQ1-TD02
Certification :
ISO9001
Place of Origin :
Japan,Korea
MOQ :
1 piece
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
100 PCS PER DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Display Mode :
TN, Normally White, Transmissive
Outline :
105.5×67.5 mm
Surface :
Antiglare
Brightness :
450 cd/m² (Typ.)
Display Colors :
16.7M (8-bit) , CIE1931 50%
Contrast Ratio :
400:1 (Typ.)
Response Time :
25 (Typ.)(Tr+Td)
Viewing Angle :
70/70/65/55 (Typ.)(CR≥10) (L/R/U/D)
Description

LB043WQ1 - TD02 4.3 inch LG LCD Panel Display 95.04×53.856 mm Active Area

LG. LCD LB043WQ1-TD02 General Features

Panel Brand : LG. LCD
Panel Model : LB043WQ1-TD02
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 4.3 inch
Resolution : 480×272(RGB) , WQVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 95.04×53.856 mm
Outline : 105.5×67.5 mm
Surface : Antiglare
Brightness : 450 cd/m² (Typ.)
Contrast Ratio : 400:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 50%
Response Time : 25 (Typ.)(Tr+Td)
Viewing Angle : 70/70/65/55 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 10S1P WLED
Signal Interface : Parallel RGB (1 ch, 8-bit) , 45 pins
Input Voltage : 2.5/3.3V (Typ.)(Low/High)


What We Can Do for You
1.Professional lithium ion battery pack for over ten years,and have our own factory.
2.Strong R&D team to support.
3.Provide best brand cell:Sanyo,Panasonic,Samsung,LG,Sony.
4.Offer OEM service for customer's order.
5.Quick reply and action.
6.competitive price, good sale and after-sales service

The reasons you choose us
1).More competitive price! As aprofessional LCD Distributor,we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.
2).Great quality! All LCD Screen we sent are with good quality guarantee,100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time,so we could promise save much more money on the shipping cost and betterservice is offered!
5).Best sale-service!Professional team to service with you before sale, on sale & after service.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LH530WX1-SH02 LG Display 5.3" 720×1280
LH500WX2-SH01 LG Display 5.0" 720×1280
LH176J03-SH02 LG Display 1.8" 220×176
LH176J04-TH01 LG Display 1.8" 176×220
LM230WF5-TJC3 LG Display 23.0" 1920×1080
LD470DUJ-SFE1 LG Display 47" 1920×1080

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

LG LCD LB043WQ1-TD02 Mechanical Features

Panel Size : 4.3 inch
Dot Resolution : 480×272(RGB) (WQVGA)
Pixel Configuration : RGB Horizontal Stripe
Pixel Density : 128 PPI
Aspect Ratio : 16:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.198×0.066 mm (H×V)
Pixel Pitch : 0.198×0.198 mm (H×V)
Weight : 50g (Typ.)
Surface : Antiglare
Active Area : 95.04×53.856 mm (H×V)
Bezel Area : 98.24×57.06 mm (H×V)
Outline Dimension : 105.5×67.5 mm (H×V)
Outline Depth : 2.97 mm
Landscape or Portrait : Landscape type
Touch Panel : Without
