Flat Rectangle Sharp LCD Panel 3.5 Inch 240×320 Character LQ035Q7DB03
Flat Rectangle Sharp LCD Panel 3.5 Inch 240×320 Character LQ035Q7DB03
Specifications
Brand Name :
SHARP
Model Number :
LQ035Q7DB03
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1 Piece
Payment Terms :
T/T, Paypal, Western Union, MoneyGram
Supply Ability :
100 PCS / DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Model :
LQ035Q7DB03
Panel Type :
a-Si TFT-LCD , Panel
Resolution :
240(RGB)×320 , QVGA
Brightness :
55 cd/m² (Typ.)
Display Colors :
TN, Normally White, Transflective
Contrast Ratio :
85:1 (Typ.)(Transmissive) 15:1 (Typ.)(Reflective)
Description

SHARP 3.5 inch LCD LQ035Q7DB03 240×320 LCD Display Panel

Descriptions for LQ035Q7DB03 LCD:

1. Panel Size : 3.5 inch
2. Dot Resolution : 240(RGB)×320 (QVGA)
3. Pixel Configuration : RGB Vertical Stripe
4. Pixel Density : 113 PPI
5. Aspect Ratio : 3:4 (H:V)
6. Form Factor : Flat Rectangle Display
7. Dot Pitch : 0.0745×0.2235 mm (H×V)
8. Pixel Pitch : 0.2235×0.2235 mm (H×V)
9. Weight : 40g (Typ.)
10. Surface : Hard coating

Technical parameters for LQ035Q7DB03 LCD:

<

Display Mode : TN, Normally White, Transflective
Brightness : 55 cd/m² (Typ.)
Contrast Ratio : 85 : 1 (Typ.) (Transmissive)
Contrast Ratio : 15:1 (Typ.) (Reflective)
Display Color : 262K (6-bit)
Response Time : 30/50 (Typ.)(Tr/Td)
Viewing Angle : 40/40/40/50 (Typ.)(CR≥2) (L/R/U/D)
Viewing Direction : 6 o'clock
Reflectance Ratio : 8/13% (Min./Typ.)
Sunlight Readable : Sunlight Readable

Our Product Advantages:

Industrial standard- and semi-custom panels also available as complete display-kit solution including Display Solutions developed high quality and long-term available TFT LCD panel or Touch Screen.

Our product line comprises the full range of LCD TFT Displays for industrial and professional applications. Display Solution is your flat panel partner for indoor and outdoor lcd panel applications also in bright sunlight or harsh environments. Premium quality or economic competitive low-cost LCD panels respectively in best price-performance ratio.

We are professional Industrial Panel Distributor of the following manufacturers: AUO, LG, Innolux, Sharp, NEC, BOE and More.

Application:

Autoelectronics,3D&Shutter,Meters&Instrument,Telecommunication,Domestic electrical appliance(Household appliance), Fuel dispensers, Office equipment, Medical &health equipment, Business related facility, Education electronics.

Some Pictures About LQ035Q7DB03 :

Flat Rectangle Sharp LCD Panel 3.5 Inch 240×320 Character LQ035Q7DB03Flat Rectangle Sharp LCD Panel 3.5 Inch 240×320 Character LQ035Q7DB03
