LED Backlighting LG LCD Panel 7.0 Inch For E - Ink Reader LB070WV6-TD06 / LB070WV6-TD08
LED Backlighting LG LCD Panel 7.0 Inch For E - Ink Reader LB070WV6-TD06 / LB070WV6-TD08
LED Backlighting LG LCD Panel 7.0 Inch For E - Ink Reader LB070WV6-TD06 / LB070WV6-TD08
LED Backlighting LG LCD Panel 7.0 Inch For E - Ink Reader LB070WV6-TD06 / LB070WV6-TD08
Specifications
Brand Name :
LG Display
Model Number :
LB070WV6-TD06 LB070WV6-TD08
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Piece
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
100 PCS Per Day
Delivery Time :
2-3 Working Days after order confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size :
7.0 inch
Surface :
Antiglare
Brightness :
350 cd/m² (Typ.)
Display Colors :
16.7M (8-bit)
Response Time :
10/15 (Typ.)(Tr/Td)
Input Voltage :
3.3V (Typ.)(VCC)
Description

LG LCD Panel , 7.0inch LB070WV6-TD06 LB070WV6-TD08 Antiglare custom lcd panels

Specifications:

Our LCD module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.

<

Panel Brand : LG Display LG Display
Panel Model : LB070WV6-TD08 LB070WV6-TD06
Frequency : 60Hz 60Hz
Lamp Type : 7S3P WLED Without Driver 7S3P WLED Without Driver
Signal Interface : Parallel RGB (1 ch, 8-bit) , 40 pins TTL (1 ch, 8-bit) , 40 pins
Input Voltage : 3.3V (Typ.) 3.3V (Typ.)(VCC)
Dot Resolution : 800×480(RGB) (WVGA) 800×480(RGB) (WVGA)
Pixel Configuration : RGB Horizontal Stripe RGB Horizontal Stripe
Pixel Density : 134 PPI 134 PPI
Aspect Ratio : 15:9 (H:V) 15:9 (H:V)
Form Factor : Flat Rectangle Display Flat Rectangle Display
Dot Pitch : 0.1893×0.0629 mm (H×V) 0.1893×0.0629 mm (H×V)
Pixel Pitch : 0.1893×0.1887 mm (H×V) 0.1893×0.1887 mm (H×V)
Weight : 107.7/112.0g (Typ./Max.) 107/112g (Typ./Max.)
Surface : Antiglare Antiglare
Active Area : 151.44×90.576 mm (H×V) 151.44×90.576 mm (H×V)
Bezel Area : 158.44×93.526 mm (H×V) 158.44×93.526 mm (H×V)
Outline Dimension : 165×104.6 mm (H×V) 165×104.6 mm (H×V)
Outline Depth : 3.3±0.3 mm 3.3±0.3 mm
Holes & Brackets : Without Without
Landscape or Portrait : Landscape type Landscape type
Touch Panel : Without Without
Display Mode : TN, Normally White, Transmissive TN, Normally White, Transmissive
Brightness : 350 cd/m² (Typ.) 350 cd/m² (Typ.)
Contrast Ratio : 500 : 1 (Typ.) (Transmissive) 500 : 1 (Typ.) (Transmissive)
Display Color : 16.7M (8-bit) 16.7M (8-bit)
Response Time : 10/15 (Typ.)(Tr/Td) 10/15 (Typ.)(Tr/Td)
Viewing Angle : 65/65/50/60 (Typ.)(CR≥10) (L/R/U/D) 65/65/50/60 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : 6 o'clock 6 o'clock
White color Chromaticity : Wx:0.313; Wy:0.329 Wx:0.313; Wy:0.329
White Variation : 1.40/1.60 (Typ./Max.)(9 points) 1.40/1.60 (Typ./Max.)(9 points)

Competitive Advantage:

1. We are a leading manufacturer of LCD products for more than 6 years.

2. We got the ISO9001 quality management system certification.

3. We have our own R&D team, and accept OEM order as per customer’s design.

4. We are the 5-years four star member of Globalsources and the Three year Gold supplier in Alibaba.

5. Our main material LCD panels all are directly imported from Samsung and LG in Korea.

6. All products win the certificate of ISO9001.

7. Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 5 days.

8. 3-years warranty is offered.

Safety:
Liquid crystal is poisonous. Do not put it in your mouth. If liquid crystal touches your skin or clothes, wash it off immediately by using soap and water.

1. Store the module in a dark room where must keep at 25±10ºC and 65%RH or less.
2. Do not store the module in surroundings containing organic solvent or corrosive gas.
3. Store the module in an anti-electrostatic container or bag.

Application:

Autoelectronics,3D&Shutter,Meters&Instrument,Telecommunication,Domestic electrical appliance (Household appliance), Fuel dispensers, Office equipment, Medical &health equipment, Business related facility, Education electronics.

Details Pictures for the LB070WV6-TD06 LB070WV6-TD08 Screen Display Panel:

LED Backlighting LG LCD Panel 7.0 Inch For E - Ink Reader LB070WV6-TD06 / LB070WV6-TD08

LED Backlighting LG LCD Panel 7.0 Inch For E - Ink Reader LB070WV6-TD06 / LB070WV6-TD08
