Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
Specifications
Brand Name :
AUO LCD Panel
Model Number :
A090VW01 V0
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1
Payment Terms :
T/T, Paypal, Western Union, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Surface :
Antiglare, Hard coating (3H)
Brightness :
250 cd/m² (Typ.)
Contrast Ratio :
500:1 (Typ.)
Display Colors :
16.7M (8-bit) , CIE1931 48%
Response Time :
4/12 (Typ.)(Tr/Td)
Pixel Configuration :
RGB Vertical Stripe
Outline :
211.7×125 mm
Description

Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS

General Features & Backlight System :

<










AUO A090VW01 V0 General Features







 Panel Brand : AUO
Panel Model : A090VW01 V0
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 9.0 inch
Resolution : 800×480(RGB) , WVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 199.2×110.16 mm
Outline : 211.7×125 mm
Surface : Antiglare, Hard coating (3H)
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 500:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 48%
Response Time : 4/12 (Typ.)(Tr/Td)
Viewing Angle : 70/70/55/70 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 3S8P WLED Without Driver
Signal Interface : TTL (1 ch, 8-bit) + SPI , 68 pins
Input Voltage : 3.3/5.5/-5.5/10/-13V (Typ.)(VCC/VDPA/VDNA/VGH/VGL)




AUO A090VW01 V0 Backlight System



 Lamp Position : Edge light type
Lamp Type : WLED
Lamp Amount : 3S8P
Lamp Shape : Array
Lamp Life Time : 10K(Min.) (Hours)
Lamp Voltage : 8.5/10.4V (Min./Max.)
Lamp Current : 160mA (Typ.)
Lamps Power Consumption : 1.55W (Typ.)
Interface Type : Connector

Guarantee and Refund :

1. All items are in good condition.

2. If the item is defective ( rarely happen ), please inform us within 3 days after you receive it and return it within warranty period ( 12 months )

3. Returned items should have original packaging and in good condition if possible. Please provide us the tracking number and the returning reason.

Features :

1. Three year standard warranty

2. 500:1 contrast ratio, and 250-nit brightness (LCD panel)
3. High quality panel with 140° x 130° viewing angle

4. Fully RoHS compliant
5. Multilingual on-screen display (OSD)

6. Optional front mount and rack mount bezels
7. LED Backlight

8. Mounting options including rear-mount and VESA mount
9. Resistive Touchscreen Technology

Competitive Advantage:

1. We are a leading manufacturer of LCD products for more than 10 years.

2. We got the ISO9001 quality management system certification.

3. We have our own R&D team, and accept OEM order as per customer’s design.

4. We are the 5-years four star member of Globalsources and the Three year Gold supplier in Alibaba.

5. Our main material LCD panels all are directly imported from Samsung and LG in Korea.

6. All products win the certificate of CE,CCC,FCC and RoHS.

7. Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 5 days.

8. 3-years warranty is offered.

Pictures of AUO A090VW01 V0 LCD Display:

Wholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPSWholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPSWholsale 9.0 inch A090VW01 V0 LCD display screen panel for Tablet PC,MID,GPS
