High Contrast Ratio 7.0 KOE LCD Panel Display TX18D16VM1CAB For Personal Computer / Notebook
High Contrast Ratio 7.0 KOE LCD Panel Display TX18D16VM1CAB For Personal Computer / Notebook
High Contrast Ratio 7.0 KOE LCD Panel Display TX18D16VM1CAB For Personal Computer / Notebook
High Contrast Ratio 7.0 KOE LCD Panel Display TX18D16VM1CAB For Personal Computer / Notebook
High Contrast Ratio 7.0 KOE LCD Panel Display TX18D16VM1CAB For Personal Computer / Notebook
High Contrast Ratio 7.0 KOE LCD Panel Display TX18D16VM1CAB For Personal Computer / Notebook
Specifications
Brand Name :
KOE LCD Display
Model Number :
TX18D16VM1CAB
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1 Piece
Payment Terms :
T/T, Paypal, Western Union, MoneyGram
Supply Ability :
100 PCS / DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Outline Depth :
10.5 (Max.) mm
Weight :
170g (Typ.)
Viewing Direction :
12 o'clock
Display Color :
262K (6-bit)
Contrast Ratio :
200 : 1 (Typ.) (Transmissive)
Vertical Frequency :
60Hz
Description

High Brightness LCD Panel 7.0" TX18D16VM1CAB Normally White KOE LCD Display

Main Parameters :

<

Panel Brand : KOE
Panel Model : TX18D16VM1CAB
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 7.0 inch
Resolution : 800(RGB)×480 , WVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 152.4×91.44 mm
Outline : 165×106×10.5 mm
Surface : Antiglare
Brightness : 600 cd/m² (Typ.)
Contrast Ratio : 200:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 60%
Response Time : 20/10 (Typ.)(Tr/Td)
Viewing Angle : 50/50/50/50 (Min.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 1 pcs CCFL Without Driver
Signal Interface : CMOS (1 ch, 6-bit) , 40 pins
Input Voltage : 3.3V (Typ.)(VDD)

Mechanical specifications:

1) The world-class manufacturer and integrator for customized LCD products from 1.44-inch to 12.1-inch with or w/o touch screen.
2) Boost of 20 years industry experience and sophisticated top rank customer service background
3) Stable long term service and delivery available relying on haier group company strength
4) With advanced management and brand vision as guideline for optimized LCD solution for customers

KOE TX18D16VM1CAB Optical Features :

<

Display Mode : TN, Normally White, Transmissive
Brightness : 600 cd/m² (Typ.)
Contrast Ratio : 200 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Color Gamut : 60% NTSC (CIE1931)
Response Time : 20/10 (Typ.)(Tr/Td)
Viewing Angle : 50/50/50/50 (Min.)(CR≥10) (L/R/U/D)
Viewing Direction : 12 o'clock
White color Chromaticity : Wx:0.300; Wy:0.310
White Variation : 1.43 (Max.)(5 points)

Pictures for KOE TX18D16VM1CAB :

High Contrast Ratio 7.0High Contrast Ratio 7.0High Contrast Ratio 7.0
