Pocket TV Small LCD Panel Normally White TM035KBZ12 Tianma 3.5 Inch LCM320×240
Pocket TV Small LCD Panel Normally White TM035KBZ12 Tianma 3.5 Inch LCM320×240
Pocket TV Small LCD Panel Normally White TM035KBZ12 Tianma 3.5 Inch LCM320×240
Pocket TV Small LCD Panel Normally White TM035KBZ12 Tianma 3.5 Inch LCM320×240
Specifications
Brand Name :
Tianma
Model Number :
TM035KBZ12
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1 Piece
Payment Terms :
T/T, Paypal, Western Union, MoneyGram
Supply Ability :
100 PCS / DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Brand :
TIANMA
Panel size :
3.5 inch
Screen Type :
LCM, a-Si TFT-LCD
Good View at :
12 o'clock
Mass :
TBD
Refresh Rate :
60Hz
Description

Normally White TM035KBZ12 Tianma 3.5 inch LCM 320×240 for pocket TV

TM035KBZ12 Information

Panel Model TM035KBZ12
Panel Brand TIANMA
Descrition a-Si TFT-LCD ,3.5 inch, 320×240
Panel Type a-Si TFT-LCD
Display Mode TN, Normally White, Transmissive
Active Area 70.08×52.56 mm
Outline 76.9×63.9×4.3 mm
Contrast Ratio 350:1 (Typ.)
Display Colors 16.7M (8-bit) , CIE1931 50%
Response Time 25/25 (Typ.)(Tr/Td)
Viewing Angle 60/60/50/60 (Typ.)(CR≥10) (L/R/U/D)
Frequency 60Hz
Lamp Type 6S1P WLED Without Driver
Signal Interface Digital RGB (8/24-bit) + SPI, CCIR601/656 , 54 pins
Input Voltage 3.3V (Typ.)

Our Promise for our LCD Panels:
You will get reply within 24 Hours and:
ΠYear warranty
ΠDay shipping
‹ Return
<
TM035KBZ12 Basic Information

Panel Model TM035KBZ12
Panel Brand TIANMA
Descrition a-Si TFT-LCD ,3.5 inch, 320×240
Panel Type a-Si TFT-LCD
Operating Temperature -20 ~ 70 °C
Storage Temperature -30 ~ 80 °C
Remarks 3 in 1 FPC

TM035KBZ12 Mechanical Features

Dot Resolution 320(RGB)×240 (QVGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 115 PPI
Aspect Ratio 4:3 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.073×0.219 mm (H×V)
Pixel Pitch 0.219×0.219 mm (H×V)
Weight TBD
Active Area 70.08×52.56 mm (H×V)
Bezel Area 72.08×54.56 mm (H×V)
Outline Dimension 76.9×63.9 mm (H×V)
Outline Depth 4.0±0.3 mm
Landscape or Portrait Landscape type
Touch Panel Embeded (4-wire Resistive, Film / Glass)

Why Choose US:
1. Prompt reply within 12 hours.
2. Understand inquiry in any language.
3. Products with top quality.
4. Very competitive prices.
5. 6-year experience in industrial LCD Screen replacements.
6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.
7. Fabulous after-sale service.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
TM240160XCFWGRA Tianma 2.2" 240×160
TM128128F6CCWGWC1 Tianma 1.44" 128×128
TM12864G3CCWGWA-1 Tianma 2.4" 128×64
TM050XYSP02 Tianma 5.0" 540×960
TM050JYHN11-00 Tianma 5.0" 720×1280
TM055JYSP08 Tianma 5.5" 720×1280
TM040XYHP01 Tianma 4.0" 640×1136
TM055JYSP03 Tianma 5.5" 720×1280
TM055JYHP03 Tianma 5.5" 720×1280
TM055JYHP01 Tianma 5.5" 720×1280
