NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
Specifications
Brand Name :
NEC
Model Number :
NL204153AC21-25
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Model :
NL204153AC21-25
Panel Brand :
NEC
Descritio :
2048×1536
Panel Type :
a-Si TFT-LCD
Active Area :
433.152×324.864 mm
Outline :
457×350×23 mm
Description

New and original NL204153AC21-25 NEC a-Si TFT-LCD ,21.3 inch, 2048×1536 for Medical Imanging

NL204153AC21-25 Basic Information

Panel Model NL204153AC21-25
Panel Brand NEC
Descrition a-Si TFT-LCD ,21.3 inch, 2048×1536
Panel Type a-Si TFT-LCD
Operating Temperature 0 ~ 60 °C
Storage Temperature -20 ~ 60 °C

Packaging & Delivery

Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.

Delivery Detail: 2-3 days after receipt of payment

Payment terms: We accept T/T, PayPal, Western Union and others.

NL204153AC21-25 Mechanical Features

Dot Resolution 2048(RGB)×1536 (QXGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 120 PPI
Aspect Ratio 4:3 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.0705×0.2115 mm (H×V)
Pixel Pitch 0.2115×0.2115 mm (H×V)
Weight 2.70/2.98Kgs (Typ./Max.)
Surface Antiglare, Hard coating (2H)
Active Area 433.152×324.864 mm (H×V)
Bezel Area 438.2×330.0 mm (H×V)
Outline Dimension 457×350 mm (H×V)
Outline Depth 21.5/23.0 (Typ./Max.) mm
Holes & Brackets Side mounting holes (4-M3) on left, right bezel
Landscape or Portrait Landscape type
Touch Panel Without

Our Service

• Long lasting product cycle for continuity thru all phases of project rollouts and servicing

• Competitive price for different brands hard disk.

• Mass stock with the better price.

• Multiple options.

• Warranty service.

• Better team to provide the before-sales, on-sale and after-sale service

• Pls send us message if any hard disk needed.

NL204153AC21-25 Optical Features

Display Mode UA-SFT, Normally Black, Transmissive
Brightness 800 cd/m² (Typ.)
Contrast Ratio 1400 : 1 (Typ.) (Transmissive)
Display Color 16.7M (8-bit)
Color Gamut 72% NTSC (CIE1931)
Response Time 20/20 (Typ.)(Tr/Td)
Viewing Angle 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction Symmetry
White color Chromaticity Wx:0.299; Wy:0.315
White Variation 1.25 (Max.)(9 points)
Sunlight Readable Y

Packing& Shipping:
Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
Guarantee:
(1) All items will be strictly tested and shipped with strong package.
(2) We have 3~6months warranty for every item, depend on the different item.
(3) We will do our best to solve any possible problem for your after sale. Please contact with us.

NL204153AC21-25 Electronics Feature

Vertical Frequency 60Hz
Reverse Scan No
Total Power Consumption 58.2W (Typ.)

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
NL6448CC20-04 NLT 6.5" 640×480
NL6448AC33-31D NLT 10.4" 640×480
NL6448AC33-27G NLT 10.4" 640×480
NL6448AC33-25 NLT 10.4" 640×480
NL6448AC33-21 NLT 10.4" 640×480
NL6448AC33-17 NLT 10.4" 640×480
NL6448AC33-09 NLT 10.4" 640×480
NL6448AC33-06 NLT 10.4" 640×480

We also have other industrial LCD panels, pls contact to us for the further information

NL204153AC21-25 pictures

NL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle DisplayNL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle DisplayNL204153AC21-25 Medical Lcd Monitor 21.3 Inch 2048×1536 Resolution Flat Rectangle Display
