New Origianl Condition LG LCD Panel 55.0 Inch 1920×1080 LD550EUE-FHB1 Frequency 60Hz
New Origianl Condition LG LCD Panel 55.0 Inch 1920×1080 LD550EUE-FHB1 Frequency 60Hz
Specifications
Brand Name :
LG Display
Model Number :
LD550EUE-FHB1
Certification :
ISO9001
Place of Origin :
Japan,Korea
MOQ :
1 piece
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
100 PCS PER DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Type :
a-Si TFT-LCD
Panel Size :
55 inch
Resolution :
1920×1080
Active Area :
1209.6×680.4 mm
Outline :
1232×708.9×28.6 mm
Contrast Ratio :
1100:1 (Typ.)
Frequency :
60Hz
Input Voltage :
12.0V (Typ.)
Description

New and origianl LD550EUE-FHB1 55.0 inch 1920×1080 Active Area 1209.6×680.4 mm Frequency 60Hz

LD550EUE-FHB1 Basic Information

Panel Model LD550EUE-FHB1
Panel Brand LG Display
Descrition a-Si TFT-LCD ,55 inch, 1920×1080
Panel Type a-Si TFT-LCD
Model Alias LD550EUE (FH)(B1)
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Remarks Integrated “Black” bezel

LD550EUE-FHB1 Mechanical Features

Dot Resolution 1920(RGB)×1080 (FHD)
Pixel Configuration RGB Vertical Stripe
Pixel Density 40 PPI
Aspect Ratio 16:9 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.210×0.630 mm (H×V)
Pixel Pitch 0.630×0.630 mm (H×V)
Weight 13.0/13.7Kgs (Typ./Max.)
Surface Antiglare (Haze 1%), Hard coating (3H)
Active Area 1209.6×680.4 mm (H×V)
Bezel Area 1214.2×685.0 mm (H×V)
Outline Dimension 1232×708.9 mm (H×V)
Outline Depth 17.0/28.6 (Typ./Max.) mm
Landscape or Portrait Landscape / Portrait
Touch Panel Without

LD550EUE-FHB1 Optical Features

Display Mode S-IPS, Normally Black, Transmissive
Brightness 450 cd/m² (Typ.)
Contrast Ratio 1100 : 1 (Typ.) (Transmissive)
Display Color 16.7M (8-bit)
Color Gamut 68% NTSC (CIE1931)
Response Time 12 (Typ.)(G to G)
Viewing Angle 89/89/89/89 (Min.)(CR≥10) (L/R/U/D)
Viewing Direction Symmetry
White color Chromaticity Wx:0.281; Wy:0.288
White Variation 1.54 (Max.)(9 points)
Sunlight Readable N

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LC470DUT-SEF2 LG Display 47" 1920×1080
LC550EGY-SHM1 LG Display 55" 3840×2160
LC550EQK-FGK3 LG Display 55" 3840×2160
LC420DUJ-SGE3 LG Display 42" 1920×1080
LH450WX3-SH01 LG Display 4.5" 720×1280
LC490EQJ-SGE2 LG Display 49" 3840×2160
LH470WX3-SH02 LG Display 4.7" 720×1280
LH600WX1-SH01 LG Display 6.0" 720×1280
LC490EQJ-SGK1 LG Display 49" 3840×2160
LC420EQJ-SGE2 LG Display 42" 3840×2160

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

Our Service

1. Quality ensurance

100% original new and A grade,

You can enjoy the real panels directly from original factory;

2. Fast reply:

Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.

3. Delivery ensurance:

Large Stock System, We have our own warehouses in Shenzhen and HongKong, with comprehensive supply lines.

4. After-Sale Service:

Professional support team to provide effective service, we are young and full of passion!

5. Professional acknowledgement of lcd panels industry to provide customers with effective advise.

We have been in original lcd panels industry for more than 6 years and know the main brands' lcd panel price system very well. What's more, we have our own engineer team to provide our customers guideline for choosing panels for their new projects.

6. Competitive quotation:

We are insistent in lcd panel industry. Our big customers network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.

Packing & Delivery for our LCD Screen Panel Replacements

1. Anti-static Bag Packing.

2. Anti-Shock Bubble Bag Packing

3. Foam and Hard Carton Packing

4. Picked up by forward and delivered by express services.
