G104X1-L04 CMO A-Si TFT Medical Lcd Panel Replacement 10.4 Inch 1024×768
G104X1-L04 CMO A-Si TFT Medical Lcd Panel Replacement 10.4 Inch 1024×768
G104X1-L04 CMO A-Si TFT Medical Lcd Panel Replacement 10.4 Inch 1024×768
G104X1-L04 CMO A-Si TFT Medical Lcd Panel Replacement 10.4 Inch 1024×768
Specifications
Brand Name :
CMO
Model Number :
G104X1-L04
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Model :
G104X1-L04
Panel Brand :
CMO
Descrition :
1024×768
Panel Type :
a-Si TFT-LCD
Active Area :
210.432×157.824 mm
Outline :
225.5×176.3×9.2 mm
Description

G104X1-L04 CMO a-Si TFT-LCD ,10.4 inch, 1024×768 for Medical Imaging

G104X1-L04 Basic Information

Panel Model G104X1-L04
Panel Brand CMO
Descrition a-Si TFT-LCD ,10.4 inch, 1024×768
Panel Type a-Si TFT-LCD
Operating Temperature -30 ~ 70 °C
Storage Temperature -30 ~ 80 °C
Remarks Rev.C1:Haze 25%; Rev.C2:Haze 22%



Shipment for the LCD Display Panels:
1. Safe & Professional package for our LCD panels.
2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4. All our LCD panel will be tested pcs by pcs before been shipped out.

G104X1-L04 Mechanical Features

Dot Resolution 1024(RGB)×768 (XGA)
Pixel Configuration RGB Vertical Stripe
Pixel Density 123 PPI
Aspect Ratio 4:3 (H:V)
Form Factor Flat Rectangle Display
Dot Pitch 0.0685×0.2055 mm (H×V)
Pixel Pitch 0.2055×0.2055 mm (H×V)
Weight 430±50g
Surface Antiglare
Active Area 210.432×157.824 mm (H×V)
Bezel Area 215.4×161.8 mm (H×V)
Outline Dimension 225.5×176.3 mm (H×V)
Outline Depth 7.96/9.2 (Typ./Max.) mm
Holes & Brackets Side mounting holes (4-M2) on left, right bezel
Landscape or Portrait Landscape type
Touch Panel Without



Guarantee:
(1) All items will be strictly tested and shipped with safe & professional package.
(2) We have 2~6months warranty for every LCD screen panels, depend on the different LCD panel models.
(3) We will do our best to solve any possible problem for your after sale. Please contact to us.

G104X1-L04 Optical Features

Display Mode Super MVA, Normally Black, Transmissive
Brightness 500 cd/m² (Typ.)
Contrast Ratio 1000 : 1 (Typ.) (Transmissive)
Display Color 262K/16.2M (6-bit / 6-bit + FRC)
Color Gamut 55% NTSC (CIE1931)
Response Time 14/11 (Typ.)(Tr/Td)
Viewing Angle 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction Symmetry
White color Chromaticity Wx:0.313; Wy:0.329
White Variation 1.25/1.40 (Typ./Max.)(5 points)
Sunlight Readable N



We can do for You:

  1. Quality Guarantee:

100% original new Hard Disk for you.
2．Fast reply:
Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.
3．Delivery Guarantee:
Large Stock System, We have our own warehouses in Shenzhen and Hong Kong, with comprehensive supply lines.
4．After-Sale Service:
Professional support team to provide effective service, we are young and full of passion!
5. Professional acknowledgement of hard disks to provide customers with effective advice.
We have been in hard disk business for more than 6 years and know the main brands' hard disk very well.
6. Competitive quotation:
Our big customer network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.

G104X1-L04 Electronics Feature

Vertical Frequency 60Hz
Reverse Scan Yes (180°)
Total Power Consumption 10W (Typ.)



Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
AE060RN01 Innolux 6.0" 800×600
F050A12-601 Innolux 5.0" 480×854
85C02502-Y21 Innolux 2.5" 320×240
V260B2-P03 Rev.C2 Innolux 26.0" 1366×768
G070YG1-P01 Innolux 7.0" 800×480
F03215-01Z Innolux 3.2" 360×480
F0352A-01U Innolux 3.5" 320×480
F07020-01D Innolux 7.0" 480×234

We also have other industrial LCD panels, pls contact to us for the further information


G104X1-L04 pictures
G104X1-L04 CMO A-Si TFT Medical Lcd Panel Replacement 10.4 Inch 1024×768G104X1-L04 CMO A-Si TFT Medical Lcd Panel Replacement 10.4 Inch 1024×768
