C065GW03 V1 AUO Car Video Screen Monitor , 6.5 Inch Auto LCD Screen LCM 400×240
C065GW03 V1 AUO Car Video Screen Monitor , 6.5 Inch Auto LCD Screen LCM 400×240
Specifications
Brand Name :
auo LCD
Model Number :
C065GW03 V1
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1
Price :
USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,HKIN ESCROW .....
Supply Ability :
500PCS/DAY
Delivery Time :
1-2days
Packaging Details :
Standard packing
Panel Model :
C065GW03 V1
Panel Brand :
AUO
Size :
6.5 inch
Panel Type :
a-Si TFT-LCD
Display Mode :
TN, Normally White
Active Area :
143.4×79.326 mm
Outline :
155×90.83 mm
Display Colors :
262K
Description

New and original C065GW03 V1 AUO 6.5 inch LCM 400×240 550 400:1 for Automotive Display

C065GW03 V1 Information

Panel Model C065GW03 V1
Panel Brand AUO
Descrition a-Si TFT-LCD ,6.5 inch, 400×240
Panel Type a-Si TFT-LCD
Display Mode TN, Normally White, Transmissive
Active Area 143.4×79.326 mm
Outline 155×90.83 mm
Surface Antiglare, Hard coating (3H)
Contrast Ratio 400:1 (Typ.)
Display Colors 262K
Response Time 15/20 (Typ.)(Tr/Td)
Viewing Angle 60/60/45/60 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type 1 pcs CCFL Without Driver
Signal Interface Parallel RGB (1 ch, 6-bit) , 55 pins
Input Voltage 3.3/9.8/15/-7V (Typ.)(VCC/AVDD/VGH/VGL)

C065GW03 V1 Basic Information

Panel Model C065GW03 V1
Panel Brand AUO
Descrition a-Si TFT-LCD ,6.5 inch, 400×240
Panel Type a-Si TFT-LCD
Model Alias C065GW03 V.1
Operating Temperature -30 ~ 85 °C
Storage Temperature -40 ~ 95 °C
Vibration Resistance 2.9G (28.4 m/s²)

C065GW03 V1 Backlight System

Lamp Position Edge light type
Lamp Type CCFL
Lamp Amount 1 pcs
Lamp Shape L shape
Lamp Life Time 10K(Min.) (Hours)
Lamp Voltage 540±50V
Lamp Current 6.5/7.0mA (Typ./Max.)
Lamp Operating Frequency 60/80Khz (Typ./Max.)
Lamp Startup Voltage 1000/1300/1580V (Max.)(Ta=+25/0/-30℃)
Interface Type Connector
Lamp Driver Board No

C065GW03 V1 Signal Interface

Signal Category TTL
Signal Class Parallel RGB (1 ch, 6-bit)
Input Voltage for Panel 3.3/9.8/15/-7V (Typ.)(VCC/AVDD/VGH/VGL)
Input Current for Panel 3.5/20/0.1/-0.1mA (Typ.)(ICC/IDD/IGH/IGL)
Interface Type FPC

Our advantages
1. Your reply will be replied within 24 hours.
2. Good service whenever.
3. OEM service
4. No MOQ request.
5. Quick delivery: 1-3 working days
6. Each LCD panel will be tested pcs by pcs by our professional testing team.
7. One Year warranty for our LCD Screen Displays.
