5.0 Inch LTG500QV-F03 Samsung LCD Panel , Normally White hard coating lcd surface
5.0 Inch LTG500QV-F03 Samsung LCD Panel , Normally White hard coating lcd surface
Specifications
Brand Name :
Samsung
Model Number :
LTG500QV-F03
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1 Piece
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size : :
5.0 inch
Resolution : :
320(RGB)×240 , QVGA
Active Area : :
101.76×76.32 mm
Contrast Ratio : :
200:1 (Min.)
Description

5.0 inch LTG500QV-F03 Samsung Normally White for Pocket TV panel

LTG500QV-F03 Information

Panel Size : 5.0 inch
Dot Resolution : 320(RGB)×240 (QVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 79 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.106×0.318 mm (H×V)
Pixel Pitch : 0.318×0.318 mm (H×V)
Weight : 108g (Typ.)
Active Area : 101.76×76.32 mm (H×V)
Bezel Area : 105.5×80.1 mm (H×V)
Outline Dimension : 130.4×93.9 mm (H×V)
Outline Depth : 7.1±0.3 mm
Landscape or Portrait : Landscape type
Touch Panel : Without

LTG500QV-F03 Information

Lamp Position : Edge light type (Bottom side)
Lamp Type : CCFL
Lamp Amount : 1 pcs
Lamp Shape : Straight
Lamp Life Time : 10K(Min.) (Hours)
Lamp Voltage : 675V (Typ.)
Lamp Current : 5.0mA (Typ.)
Interface Type : Connector
Backlight Interface Brand Model Pin Pitch Pins Amount Configuration
JST BHSR-02VS-1 3.5 mm 2 pins 1 pcs BLL-2PINS-HL
Lamp Driver Board : No

Company Strength:

1>ISO9001 certificated.

2> Competitive Price and Short Lead-time

3> Professional Team with Rich Experiences in LCD Screen International trade.

4> Small MOQ Support & Fast Response to Customers

5> Long Product Life Time

6> Each LCD will be tested pcs by pcs before shipment to guarantee the quality.

7> We are distributor for the hard-to-find LCD Screen Panels, contained but not limited to Medical LCD Panel, Aerospace LCD Display, Gaming LCD Screen, Military LCD Replacements, Kiosk LCD Panels, Transportation LCD Panels.

8> The LCD brands we can provide to you contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more.

Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
AMS302AK03 Samsung 3.0" 720×480
AMS353FD01-0 Samsung 3.5" 480×800
AMS499QP89-0 Samsung 5.0" 1080×1920
AMS529BY03 Samsung 5.3" 1080×1920
SDC 1.63 320×320 Samsung 1.63" 320×320
AMS499QP42-0 Samsung 5.0" 1080×1920

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Packaging & Delivery

Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.

Delivery Detail: 2-3 days after receipt of payment

Payment terms: We accept T/T, PayPal, Western Union and others.
