5.0 Inch LTP500GV-F01 Samsung LCD Panel 480×640 with 75.6×100.8 mm Active Area
5.0 Inch LTP500GV-F01 Samsung LCD Panel 480×640 with 75.6×100.8 mm Active Area
Specifications
Brand Name :
Samsung
Model Number :
LTP500GV-F01
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1 Piece
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size : :
5.0 inch
Resolution : :
480(RGB)×640 , VGA
Active Area : :
75.6×100.8 mm
Outline : :
83.84×113.2×4.8 mm
Brightness : :
200 cd/m² (Typ.)
Display Colors : :
262K (6-bit) , CIE1931 40%
Description

5.0 Inch LTP500GV-F01 Samsung LCD Panel 480×640 with 75.6×100.8 mm Active Area

LTP500GV-F01 Information

Panel Size : 5.0 inch
Dot Resolution : 480(RGB)×640 (VGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 161 PPI
Aspect Ratio : 3:4 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0525×0.1575 mm (H×V)
Pixel Pitch : 0.1575×0.1575 mm (H×V)
Weight : 85/90g (Typ./Max.)
Active Area : 75.6×100.8 mm (H×V)
Outline Dimension : 83.84×113.2 mm (H×V)
Outline Depth : 4.5±0.3 mm
Landscape or Portrait : Portrait type
Touch Panel : Embeded (4-wire Resistive)


LTP500GV-F01 Information

Display Mode : TN, Normally White, Transmissive
Brightness : 200 cd/m² (Typ.)
Contrast Ratio : 250 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Color Gamut : 40% NTSC (CIE1931)
Response Time : 35 (Typ.)(Tr+Td)
Viewing Angle : 40/30/50/50 (Min.)(CR≥10) (L/R/U/D)
White Variation : 1.32 (Max.)(9 points)
Sunlight Readable : N


Guarantee:
(1) All items will be strictly tested and shipped with safe & professional package.
(2) We have 2~6months warranty for every LCD screen panels, depend on the different LCD panel models.
(3) We will do our best to solve any possible problem for your after sale. Please contact to us.
Return and Refund:
(1) Please notify us ASAP if the LCD Displays you received is defective. Please do not raise any dispute without communication.
(2) All LCD panels must be informed before returning. Defective item must be reported and returned within our warranty period.
(3) Returned item must have original package and be in good condition if possible, pls provide us the tracking number and returning reason.

Why do you choose us?
• Quick response to clients' enquiries within 24hrs.
• More than 6-year experience in LCD screen field and professional team communication team.
•Value quality and long-term cooperation to reach win-win relationship.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
AMS549HQ02 Samsung 5.5" 720×1280
AMS520BQ12-0 Samsung 5.2" 1080×1920
AMS497DX12-0 Samsung 5.0" 720×1280
AMS163AN01 Samsung 1.63" 320×320
AMS510CV02 Samsung 5.1" 1080×1920
AMS510CV01 Samsung 5.1" 1080×1920
AMS302AK03 Samsung 3.0" 720×480
AMS353FD01-0 Samsung 3.5" 480×800
AMS499QP89-0 Samsung 5.0" 1080×1920
AMS529BY03 Samsung 5.3" 1080×1920


We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
