22.0 inch M220Z1-L03 Hard coating Innolux LCD Panel 473.76×296.1 mm for Desktop Monitor
22.0 inch M220Z1-L03 Hard coating Innolux LCD Panel 473.76×296.1 mm for Desktop Monitor
Specifications
Brand Name :
Innolux
Model Number :
M220Z1-L03
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Model :
M220Z1-L03
Panel Type :
a-Si TFT-LCD , LCM
Display Colors :
16.7M (6-bit + Hi-FRC) , CIE1931 72%
Brightness :
300 cd/m² (Typ.)
Response Time :
1.3/3.7 (Typ.)(Tr/Td)
Signal Interface :
LVDS (2 ch, 8-bit) , 30 pins
Supply Ability :
500PCS/DAY
Description

22.0 inch M220Z1-L03 Hard coating Innolux LCD Panel 473.76×296.1 mm for Desktop Monitor

Packaging & Shipping:

Delivery Information:
Our professional testing team will test the LCD panels pcs by pcs, to make sure the LCD screen sent out are with good quality.
Shipping Method:
By Express: FedEx, DHL, EMS, TNT, UPS,
By Logistics: By air
Shipping Time:
From Monday to Saturday 8:00am-17:30pm
Shipping Address:
If by T/T, shipping address as communicate.

What is our advantage?

Factory Experience: More than 6 years of experience in the agency & sourcing line of Hard-to-find LCD Screen replacements.

Delivery Quantity: 50-100 cartons shipped by DHL every week

Supply Ability: 100 pcs Panels per day.

Supply Area: All over the word (Most of North America, South America, Europe, Japan, Korea and more.)

Warranty: 12 months.

M220Z1-L03 Innolux LCD Panel Information

Panel Brand : CMO
Panel Model : M220Z1-L03
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 22.0 inch
Resolution : 1680(RGB)×1050 , WSXGA+
Display Mode : TN, Normally White, Transmissive
Active Area : 473.76×296.1 mm
Outline : 493.7×320.1 mm
Surface : Antiglare (Haze 25%), Hard coating (3H)
Brightness : 300 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (6-bit + Hi-FRC) , CIE1931 72%
Response Time : 1.3/3.7 (Typ.)(Tr/Td)
Viewing Angle : 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 4 pcs CCFL Without Driver
Signal Interface : LVDS (2 ch, 8-bit) , 30 pins
Input Voltage : 5.0V (Typ.)

Panel Size : 22.0 inch
Dot Resolution : 1680(RGB)×1050 (WSXGA+)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 90 PPI
Aspect Ratio : 16:10 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.094×0.282 mm (H×V)
Pixel Pitch : 0.282×0.282 mm (H×V)
Weight : 2.82/2.87Kgs (Typ./Max.)
Surface : Antiglare (Haze 25%), Hard coating (3H)
Active Area : 473.76×296.1 mm (H×V)
Bezel Area : 477.7×300.1 mm (H×V)
Outline Dimension : 493.7×320.1 mm (H×V)
Outline Depth : 16.5/17.0 (Typ./Max.) mm
Holes & Brackets : Side mounting holes (8-M3)
Landscape or Portrait : Landscape type
Touch Panel : Without

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
V650DJ4-QS5 Rev.M1 Innolux 65" 3840×2160
N080ICP-G01 CELL Innolux 8.0" 800×1280
DE080NA-01D Innolux 8.0" 800×480
AT080YN01 Innolux 8.0" 1024×600
PG055IA-03H Innolux 5.5" 720×1280
PP057IC-01A Innolux 5.7" 1080×1920
PG055IC-07F Innolux 5.5" 1080×1920
PB050IC-01D Innolux 5.0" 1080×1920
PG050IA-02A Innolux 5.0" 540×960
V400DK1-QE2 Innolux 40" 3840×2160
V650DK1-QS3 Innolux 65" 3840×2160

M220Z1-L03 Innolux LCD Panel Picture

22.0 inch M220Z1-L03 Hard coating Innolux LCD Panel 473.76×296.1 mm for Desktop Monitor
