21.3 inch NL160120AC27-37 NLT LCD Pane with 432×324 mm Active Area
21.3 inch NL160120AC27-37 NLT LCD Pane with 432×324 mm Active Area
Specifications
Brand Name :
NLT
Model Number :
NL160120AC27-37
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Supply Ability :
500PCS/DAY
Input Voltage :
12.0V (Typ.)
Signal Interface :
LVDS (2 ch, 8-bit) , 30 pins
Frequency :
60Hz
Response Time :
20/20 (Typ.)(Tr/Td)
Display Colors :
16.7M (8-bit) , CIE1931 72%
Surface :
Antiglare, Hard coating (2H)
Description

21.3 inch NL160120AC27-37 NLT LCD Pane with 432×324 mm Active Area

NL160120AC27-37 Specification

Panel Brand : NLT
Panel Model : NL160120AC27-37
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 21.3 inch
Resolution : 1600(RGB)×1200 , UXGA
Display Mode : SFT, Normally Black, Transmissive
Active Area : 432×324 mm
Outline : 457×350×22 mm
Surface : Antiglare, Hard coating (2H)
Brightness : 900 cd/m² (Typ.)
Contrast Ratio : 1400:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 72%
Response Time : 20/20 (Typ.)(Tr/Td)
Viewing Angle : 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : WLED Embedded (LED Driver)
Signal Interface : LVDS (2 ch, 8-bit) , 30 pins
Input Voltage : 12.0V (Typ.)

Our advantages in the LCD Screen market:
1.Better price
2.Fast delivery
3.Top quality
4.First class after - sales service
5.No memory effect
6.Sourcing lines & Distributors for the EOL LCD.

FAQ

Q1: What's the quality of your Hard Disk?

A: Various brands for hard disk etc. We are available to meet your different requirements.

Q2: What is your return and refund policy?

A: We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.

Q4: How long is the lead time?

A: The lead time is about 2-3 working days after receipt of payment.

Q5: Do you accept sample order?

A:Yes, sample order is welcome.

Q6: How can I get the quotation?

A: Please enquire via Skype, Email, Whatsapp or telephone. You will get reply within 24 hours.

Panel Size :

 21.3 inch
Dot Resolution : 1600(RGB)×1200 (UXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 94 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.090×0.270 mm (H×V)
Pixel Pitch : 0.270×0.270 mm (H×V)
Weight : 2.70/2.98Kgs (Typ./Max.)
Surface : Antiglare, Hard coating (2H)
Active Area : 432×324 mm (H×V)
Bezel Area : 438.2×330.0 mm (H×V)
Outline Dimension : 457×350 mm (H×V)
Outline Depth : 21.5±0.5 mm
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
NL204153BC21-09 NLT 21.3" 2048×1536
NL128102BC31-02 NLT 20.1" 1280×1024
NL8060BC26-28D NLT 10.4" 800×600
NL280210AM15-04A NLT 21.3" 2800×2100
NL2432HC22-50K NLT 3.5" 240×320
NL160120BC27-19E NLT 21.3" 1600×1200
NL204153BM21-05 NLT 21.3" 2048×1536
NL204153BM21-04A NLT 21.3" 2048×1536
NL204153BM21-04 NLT 21.3" 2048×1536
NL204153BM21-02 NLT 21.3" 2048×1536
NL6448BC33-29 NLT 10.4" 640×480
NL10276BC20-11 NLT 10.4" 1024×768
NL10276BC28-01 NLT 14.1" 1024×768

NL160120AC27-37 Picture
