M190A1- L0A 19.0 LCM industrial flat panel display 1440×900 16.7M CCFL LVDS
M190A1- L0A 19.0 LCM industrial flat panel display 1440×900 16.7M CCFL LVDS
Specifications
Brand Name :
AUO
Model Number :
M190A1-L0A
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1
Price :
500PCS/DAY
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Type : :
a-Si TFT-LCD , LCM
Resolution : :
1440(RGB)×900 , WXGA+
Active Area : :
408.24×255.15 mm
Surface : :
Antiglare (Haze 25%), Hard coating (3H)
Description

M190A1- L0A 19.0" LCM industrial flat panel display 1440×900 16.7M CCFL LVDS

Panel Brand : CMO
Panel Model : M190A1-L0A
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 19.0 inch
Resolution : 1440(RGB)×900 , WXGA+
Display Mode : TN, Normally White, Transmissive
Active Area : 408.24×255.15 mm
Outline : 428×278×17.6 mm
Surface : Antiglare (Haze 25%), Hard coating (3H)
Brightness : 300 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (6-bit + Hi-FRC) , CIE1931 72%
Response Time : 1.5/3.5 (Typ.)(Tr/Td)
Viewing Angle : 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 4 pcs CCFL Without Driver
Signal Interface : LVDS (2 ch, 8-bit) , 30 pins
Input Voltage : 5.0V (Typ.)

Panel Size : 19.0 inch
Dot Resolution : 1440(RGB)×900 (WXGA+)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 89 PPI
Aspect Ratio : 16:10 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0945×0.2835 mm (H×V)
Pixel Pitch : 0.2835×0.2835 mm (H×V)
Weight : 1.90/1.94Kgs (Typ./Max.)
Surface : Antiglare (Haze 25%), Hard coating (3H)
Active Area : 408.24×255.15 mm (H×V)
Bezel Area : 412.2×259.2 mm (H×V)
Outline Dimension : 428×278 mm (H×V)
Outline Depth : 17.6 (Max.) mm
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without

M190A1-L0A Innolux LCD Panel 19.0" LCM 1440×900 300 1000:1 16.7M CCFL LVDS
