TX09D30VM1EBA KOE LCD Display , 262K 3.5 tft lcd module 64×86 mm Outline
TX09D30VM1EBA KOE LCD Display , 262K 3.5 tft lcd module 64×86 mm Outline
Specifications
Brand Name :
KOE
Model Number :
TX09D30VM1EBA
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1
Payment Terms :
Western Union, T/T, MoneyGram, T/T
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Type :
a-Si TFT-LCD , LCM
Panel Size :
3.5 inch
Resolution :
240(RGB)×320 , QVGA
Display Mode :
TN, Normally White, Transmissive
Active Area :
64×86 mm
Description

TX09D30VM1EBA KOE LCD Display KOE 3.5 with 64×86 mm Outline

Feedback:

(1) Your early confirmation will be highly appreciated after receiving the item.

(2) If you are satisfied with our item, pls contact to us also for other items, actually, we are not only own professional sourcing lines for AUO, LG, Samsung, Tianma, KOE, NEC, Hitachi, Optrex and more.

Competitive Advantage:

1. We are a leading vendor & distributor for the LCD panels for more than 6 years.

2. We got the ISO9001 quality management system certification.

3. We have our own sourcing line & agency for the hard-to-find & shortage LCD panel models.

4. We are the professional team for the LCD screen sourcing & international trade with 6-year experience.

5. Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 1-3 working days.

6. 1-year warranty is offered.

7. All LCD Panel will be tested before shipment.

8. We are the vendor & distributor in LCD panel area already for 6 years. We own our professional & competitive LCD screen sourcing line.

Here comes our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
SP24V01L0ALZZ KOE 9.4" 640×480
SP14N02L6ALCZ KOE 5.1" 240×128
SP12N01L6ALCZ KOE 4.8" 256×64
SP24V001-A KOE 9.4" 640×480
SP10Q010-T KOE 3.8" 320×240
SP10Q010-ZZA KOE 3.8" 320×240
SP10Q010-TZA KOE 3.8" 320×240

Pls contact to us for more stock information: salespm@nselectronic.com.hk

TX09D30VM1EBA Information

Panel Size : 3.5 inch
Dot Resolution : 240(RGB)×320 (QVGA)
Pixel Configuration : RGB Vertical Stripe
Aspect Ratio : 3:4 (H:V)
Form Factor : Flat Rectangle Display
Outline Dimension : 64×86 mm (H×V)
Outline Depth : 3.12 mm
Landscape or Portrait : Portrait type
Touch Panel : Without
Display Mode : TN, Normally White, Transmissive
Brightness : 430 cd/m² (Typ.)
Contrast Ratio : 300 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Sunlight Readable : N
