Color KCG047QV1AA-A210 KOE LCD Display , 4.7 inch Antiglare hard coating lcd surface
Color KCG047QV1AA-A210 KOE LCD Display , 4.7 inch Antiglare hard coating lcd surface
Specifications
Brand Name :
Kyocera
Model Number :
KCG047QV1AA-A210
Certification :
ISO9001
Place of Origin :
korea
MOQ :
1
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
500PCS/DAY
Delivery Time :
2-3 Working Days after order confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Brand :
Kyocera
Panel Model :
KCG047QV1AA-A210
Panel Type :
CSTN-LCD , LCM
Panel Size :
4.7 inch
Resolution :
320(RGB)×240 , QVGA
Display Mode :
STN, Normally Black, Transmissive
Description

Color KCG047QV1AA-A210 Kyocera LCD Panel 4.7 inch Antiglare

KCG047QV1AA-A210 Detail

Panel Brand : Kyocera
Panel Model : KCG047QV1AA-A210
Panel Type : CSTN-LCD , LCM
Panel Size : 4.7 inch
Resolution : 320(RGB)×240 , QVGA
Display Mode : STN, Normally Black, Transmissive
Active Area : 95.98×71.98 mm
Outline : 122.4×90×11.4 mm
Surface : Antiglare
Brightness : 160 cd/m² (Typ.)
Contrast Ratio : 30:1 (Typ.)
Display Colors : Color
Response Time : 490 (Typ.)(Tr+Td)
Viewing Angle : 50/50/15/35 (Typ.)(CR≥2) (L/R/U/D)
Frequency : 75Hz
Lamp Type : 1 pcs CCFL Without Driver
Input Voltage : 3.3/5.0V (Typ.)(VDD)

Company Strength:

1>ISO9001 certificated.

2> Competitive Price and Short Lead-time

3> Professional Team with Rich Experiences in LCD Screen International trade.

4> Small MOQ Support & Fast Response to Customers

5> Long Product Life Time

6> Each LCD will be tested pcs by pcs before shipment to guarantee the quality.

7> We are distributor for the hard-to-find LCD Screen Panels, contained but not limited to Medical LCD Panel, Aerospace LCD Display, Gaming LCD Screen, Military LCD Replacements, Kiosk LCD Panels, Transportation LCD Panels.

8> The LCD brands we can provide to you contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more.

Panel Size : 4.7 inch
Dot Resolution : 320(RGB)×240 (QVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 84 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.100×0.300 mm (H×V)
Pixel Pitch : 0.300×0.300 mm (H×V)
Weight : 120g
Surface : Antiglare
Active Area : 95.98×71.98 mm (H×V)
Bezel Area : 100.6×76.6 mm (H×V)
Outline Dimension : 122.4×90 mm (H×V)
Outline Depth : 7.6/11.4 (Typ./Max.) mm
Landscape or Portrait : Landscape type
Touch Panel : Without

FAQ

Q1: What's the quality of your Hard Disk?

A: Various brands for hard disk etc. We are available to meet your different requirements.

Q2: What is your return and refund policy?

A: We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.

Q4: How long is the lead time?

A: The lead time is about 2-3 working days after receipt of payment.

Q5: Do you accept sample order?

A:Yes, sample order is welcome.

Q6: How can I get the quotation?

A: Please enquire via Skype, Email, Whatsapp or telephone. You will get reply within 24 hours.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
SP24V01L0ALZZ KOE 9.4" 640×480
SP14N02L6ALCZ KOE 5.1" 240×128
SP12N01L6ALCZ KOE 4.8" 256×64
SP24V001-A KOE 9.4" 640×480
SP10Q010-T KOE 3.8" 320×240
SP10Q010-ZZA KOE 3.8" 320×240
SP10Q010-TZA KOE 3.8" 320×240

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

KCG047QV1AA-A210 Picture
