Normally White LTA084C272F TOSHIBA 8.4 inch with 170.4×127.8 mm Active Area
Normally White LTA084C272F TOSHIBA 8.4 inch with 170.4×127.8 mm Active Area
Specifications
Brand Name :
TOSHIBA
Model Number :
LTA084C272F
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1 Piece
Payment Terms :
Western Union, T/T, MoneyGram
Supply Ability :
500PCS/DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Brand : :
Toshiba Mobile Display
Panel Size : :
8.4 inch
Display Mode : :
TN, Normally White, Transmissive
Outline : :
199.5×149.5 mm
Description

Normally White LTA084C272F TOSHIBA 8.4 inch with 170.4×127.8 mm Active Area

LTA084C272F Specification

Panel Size : 8.4 inch
Dot Resolution : 800(RGB)×600 (SVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 119 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.071×0.213 mm (H×V)
Pixel Pitch : 0.213×0.213 mm (H×V)
Weight : 540g (Typ.)
Active Area : 170.4×127.8 mm (H×V)
Bezel Area : 174.8×132.2 mm (H×V)
Outline Dimension : 199.5×149.5 mm (H×V)
Outline Depth : 13.0 (Typ.) mm
Holes & Brackets : Face mounting holes
Landscape or Portrait : Landscape type
Touch Panel : Embeded (4-wire Resistive)

LTA084C272F Specification

Lamp Position : Edge light type (Top side)
Lamp Type : CCFL
Lamp Amount : 2 pcs
Lamp Shape : Straight
Lamp Life Time : 50K(Typ.) (Hours)
Lamp Replaceable : Replaceable
Lamp Voltage : 430V (Typ.)
Lamp Current : 4.0/6.0/6.5mA (Min./Typ./Max.)
Lamp Startup Voltage : 1300/1600V (Min./Max.)(Ta=0℃)
Interface Type : Connector
Backlight Interface Brand Model Pin Pitch Pins Amount Configuration
JST BHR-04VS-1 4.0 mm 4 pins 1 pcs BLL-4PINS-HHNL
Lamp Driver Board : No

What is Our Advantage?

1. We are the professional supplier of the industrial LCD Screen Replacements, located in the biggest components center of the world.

2. We can provide the one-stop purchase service.

3. Our clients can grow their business by focusing on their sales, ware-housing and distribution while we take care of their China buying.

4. Client relationship and production management are the key factors that ensure successful China buying. Your account will be managed by our professional project managers.

5. Fast delivery.

6. Reasonable price.

We can do for You:

1.Quality Guarantee:

100% original new Hard Disk for you.

2．Fast reply:

Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.

3．Delivery Guarantee:

Large Stock System, We have our own warehouses in Shenzhen and Hong Kong, with comprehensive supply lines.

4．After-Sale Service:

Professional support team to provide effective service, we are young and full of passion!

5. Professional acknowledgement of hard disks to provide customers with effective advice.

We have been in hard disk business for more than 6 years and know the main brands' hard disk very well.

6. Competitive quotation:

Our big customer network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LTA070B0C1A TOSHIBA 7.0" 480×234
LTA070B070F TOSHIBA 7.0" 800×480
LTA070A251A TOSHIBA 7.0" 480×234
LTA040B470A TOSHIBA 4.0" 480×234
LT057AA34C00 TOSHIBA 5.7" 320×240
LT057AA34B00 TOSHIBA 5.7" 320×240
LTA106C211F TOSHIBA 10.6" 1280×768
LTD131EWHK TOSHIBA 13.1" 1366×768

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
