High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800
High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800
High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800
High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800
High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800
High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800
Specifications
Brand Name :
LG LCD Panel
Model Number :
LP094WX1-SLA2
Certification :
ISO9001
Place of Origin :
Japan/Taiwan
MOQ :
1 piece
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
3000 PCS PER DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Surface :
Anti-Scatter
Brightness :
320 cd/m² (Typ.)
Aspect Ratio :
16:10 (H:V)
Panel Size :
9.4 inch
Dot Resolution :
1280(RGB)×800 (WXGA)
Touch Panel :
Embeded (Projected Capacitive Touch)
Contrast Ratio :
600:1 (Typ.)
Display Colors :
262K (6-bit) , CIE1931 50%
Description

High Brightness LG LCD Panel, 9.4 inch LP094WX1-SLA2 Projected Capacitive Touch with 1280*800

Product Application:

Our LCD module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.

LG Display LP094WX1-SLA2 Mechanical Features:


Panel Size : 9.4 inch
Dot Resolution : 1280(RGB)×800 (WXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 161 PPI
Aspect Ratio : 16:10 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0525×0.1575 mm (H×V)
Pixel Pitch : 0.1575×0.1575 mm (H×V)
Weight : 235g (Max.)
Surface : Anti-Scatter
Active Area : 201.6×126 mm (H×V)
Bezel Area : 203.92×128.32 mm (H×V)
Outline Dimension : 237.7×161.45 mm (H×V)
Outline Depth : 4.65/6.5 (Typ./Max.) mm
Landscape or Portrait : Landscape type
Touch Panel : Embeded (Projected Capacitive Touch)
Panel Cover : With Cover Lens

Specifications :

Panel Brand : LG Display
Panel Model : LP094WX1-SLA2
Panel Type : a-Si TFT-LCD , Assembly
Panel Size : 9.4 inch
Resolution : 1280(RGB)×800 , WXGA
Active Area : 201.6×126 mm
Outline : 237.7×161.45×6.5 mm
Surface : Anti-Scatter
Brightness : 320 cd/m² (Typ.)
Contrast Ratio : 600:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 50%
Viewing Angle : 80/80/80/80 (Min.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Signal Interface : LVDS (1 ch, 6-bit) , 39 pins

LG Display LP094WX1-SLA2 Backlight System:

Lamp Position : Edge light type
Lamp Type : WLED
Lamp Amount : 6 strings
Lamp Shape : 6 strings
Lamp Life Time : 15K(Min.) (Hours)
Lamps Power Consumption : 1.74/1.80W (Typ./Max.)
Interface Type : Included in panel signal interface
Lamp Driver Board : No

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LH550WF3-SH01 LG Display 5.5" 1080×1920
LC320DXY-SHA3 LG Display 31.5" 1366×768
LC490EQL-SHA2 LG Display 49" 3840×2160
LC430EQL-SHA2 LG Display 43" 3840×2160
LC430DUY-SHA2 LG Display 43" 1920×1080
LC550EGY-SHM2 LG Display 55" 3840×2160
LC320DXJ-SFA9 LG Display 31.5" 1366×768
LH400WV3-SD06 LG Display 4.0" 480×800
LH300Q02-SD01 LG Display 3.0" 240×320

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

Delivery time is approx:

United States / United Kingdom / Australia 7-14 working days.

Canada 7-25 working days.

France / Spain / Germany may take 7-20 working days.

Eastern Europe may take up to 16-30 working days.

Italy / Brazil / South America may take up to 30-50 working days.

Shipped by DHL Express (Need 3-6 working days to arrive)
