670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
670g and 800*600 LTD121C31S Industrial LCD Displays TN , Transmissive with 12.1 inch
Specifications
Brand Name :
Industrial LCD Displays
Model Number :
LTD121C31S
Certification :
ISO9001
Place of Origin :
Japan/Taiwan
MOQ :
1 piece
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
3000 PCS PER DAY
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Holes & Brackets :
Face mounting holes (4-Φ3.4) on left, right bezel
Operating Temperature :
-10 ~ 65 °C
Storage Temperature :
-20 ~ 80 °C
Pixel Density :
82 PPI
Outline Depth :
11.0 (Max.) mm
Bezel Area :
249.0×187.5 mm (H×V)
Dot Resolution :
800(RGB)×600 (SVGA)
Landscape or Portrait :
Landscape type
Description

670g and 800*600 LTD121C31S Industrial LCD Displays TN, Normally White, Transmissive with 12.1 inch

Advantages of N&S For the TFT LCD Screen:

Wholesale Price: We are the agency & professional sourcing buyer for the various branded LCD screens.
Fast delivery: We own the stock for the EOL & hard-to-find LCD screen replacements.
High Quality: Each LCD Screen will be tested pcs by pcs before shipments.
Good service: Professional international trade sales team & LCD panels testing team for 6 years.
One year international warranty.

Feature:
1) 100% Brand New and never used Touch Screen Digitizer.
2) Tested before shipping and 100% working well.
3) Delivery in 3 working days after payment confirmed.
4) Excellent after-sale service.
5) Great replacements for your LCD panels’ sourcing replenishment.
6) Each screen will be tested before shipping and 100% working guarantee.

Toshiba Matsushita LTD121C31S General Features

Panel Brand : Toshiba Matsushita
Panel Model : LTD121C31S
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 12.1 inch
Resolution : 800(RGB)×600 , SVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 246×184.5 mm
Outline : 278.3×209×11 mm
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 450:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 10/25 (Typ.)(Tr/Td)
Viewing Angle : 60/60/50/50 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type : 2 pcs CCFL Without Driver
Signal Interface : CMOS (1 ch, 6-bit) , 32 pins
Input Voltage : 3.3V (Typ.)(VDD)

Mechanical Features

Panel Size : 12.1 inch
Dot Resolution : 800(RGB)×600 (SVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 82 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.1025×0.3075 mm (H×V)
Pixel Pitch : 0.3075×0.3075 mm (H×V)
Weight : 670g (Typ.)
Active Area : 246×184.5 mm (H×V)
Bezel Area : 249.0×187.5 mm (H×V)
Outline Dimension : 278.3×209 mm (H×V)
Outline Depth : 11.0 (Max.) mm
Holes & Brackets : Face mounting holes (4-Φ3.4) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
ED060KG1 E Ink 6.0" 1072×1448
ED060KC1 E Ink 6.0" 1072×1448
ED060XC9 E Ink 6.0" 758×1024
ED060XD7 E Ink 6.0" 758×1024
ED080TC1 E Ink 8.0" 1600×1200
ED097TC1 E Ink 9.7" 1200×825
ET047TC1 E Ink 4.7" 540×960

Other details:

Display Mode : TN, Normally White, Transmissive
Brightness : 250 cd/m² (Typ.)
Contrast Ratio : 450 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Response Time : 10/25 (Typ.)(Tr/Td)
Viewing Angle : 60/60/50/50 (Typ.)(CR≥10) (L/R/U/D)

Lamp Position : Edge light type (Top side)
Lamp Type : CCFL
Lamp Amount : 2 pcs
Lamp Shape : Straight
Lamp Life Time : 50K(Typ.) (Hours)
Lamp Replaceable : Replaceable
Lamp Voltage : 520V (Typ.)
Lamp Current : 3.0/6.5mA (Min./Max.)
Lamp Startup Voltage : 1200/1900V (Min./Max.)(Ta=0℃)
Interface Type : Connector

Why Choose Us?

1. Prompt reply within 12 hours.

2. Understand inquiry in any language.

3. Products with top quality.

4. Very competitive prices.

5. 6-year experience in international trade for the LCD display sourcing.

6. Fabulous after-sale service.

7. The brand we could hand for the LCD Panel contained but not limited to AUO, Chimei, Hitachi, Innolux, KOE, Tianma, LG, NEC, Samsung, Sharp, Optrex and more other industrial LCD Screen.

TFT LCD Module series:

1. Our standard TFT LCD module size:

1.5", 2.0", 2.2", 2.5", 3.0", 3.5", 4.0", 4.2", 4.3", 4.7", 5.0", 5.5", 5.7", 6.0", 6.4", 7.0", 8.0", 10.1", 10.4", 12.1", etc.

2. Our TFT LCD module brands:

NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE etc.

3. Transflective / sun readable TFT LCD.

4. We are pretty specialize in the EOL & Hard-to-find LCD screen panel.
