NEC NL8060AC26-17 LCD Panel with 211.2×158.4 mm Active Area
NEC NL8060AC26-17 LCD Panel with 211.2×158.4 mm Active Area
Specifications
Brand Name :
NEC
Model Number :
NL8060AC26-17
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
100 PCS / DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Panel Size :
10.4 inch
Resolution :
800(RGB)×600 , SVGA
Display Mode :
TN, Normally White, Transmissive
Brightness :
280 cd/m² (Typ.)
Contrast Ratio :
300:1 (Typ.)
Display Colors262K (6-bit) , CIE1931 43% :
262K (6-bit) , CIE1931 43%
Description

NEC NL8060AC26-17 LCD Panel with 211.2×158.4 mm Active Area

NL8060AC26-17 Quick Details:

Panel Brand : NEC
Panel Model : NL8060AC26-17
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 10.4 inch
Resolution : 800(RGB)×600 , SVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 211.2×158.4 mm
Outline : 243×185.1 mm
Surface : Antireflection
Brightness : 280 cd/m2 (Typ.)
Contrast Ratio : 300:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 43%
Response Time : 15/65 (Typ.)(Tr/Td)
Viewing Angle : 50/50/35/45 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 2 pcs CCFL
Signal Interface : CMOS (1 ch, 6-bit) , 41 pins
Input Voltage : 3.3/5.0V (Typ.)(VCC)

NEC NL8060AC26-17 Mechanical Features

Panel Size : 10.4 inch
Dot Resolution : 800(RGB)×600 (SVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 96 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.088×0.264 mm (H×V)
Pixel Pitch : 0.264×0.264 mm (H×V)
Weight : 520g (Typ.)
Surface : Antireflection
Active Area : 211.2×158.4 mm (H×V)
Bezel Area : 215.4×161.8 mm (H×V)
Outline Dimension : 243×185.1 mm (H×V)
Outline Depth : 11.5 (Max.) mm
Holes & Brackets : Face mounting holes (4 pcs)
Landscape or Portrait : Landscape type
Touch Panel : Without

What is Our Advantage?

1. We are the professional supplier of the industrial LCD Screen Replacements, located in the biggest components center of the world.

2. We can provide the one-stop purchase service.

3. Our clients can grow their business by focusing on their sales, ware-housing and distribution while we take care of their China buying.

4. Client relationship and production management are the key factors that ensure successful China buying. Your account will be managed by our professional project managers.

5. Fast delivery.

6. Reasonable price.

FAQ

1. Q: Where can I get the price?

A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.

2. Q: How can I get a sample to check your quality?

A: After price confirmation, you can require for samples to check our quality.

3. Q: What about the lead time for mass production?

A: It depends on your order quantity and the season you place the order.

4. Q: What are your terms of payment?

A: We accept T/T, Western Union, MoneyGram, PayPal.

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
ED133TT1 E Ink 13.3" 2200×1650
ED060SD1 E Ink 6.0" 600×800
ED060SCT E Ink 6.0" 600×800
ET043OC1 E Ink 4.4" 360×640
EN133UT1 E Ink 13.3" 1600×1200
ED047TC1 E Ink 4.7" 540×960
ED133UT1 E Ink 13.3" 1600×1200
ES133UT1 E Ink 13.3" 1600×1200
ED060SCQ E Ink 6.0" 600×800

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

NL8060AC26-17 Picture

NEC NL8060AC26-17 LCD Panel with 211.2×158.4 mm Active Area
