4.3 Inch Sharp LCD Panel LQ043T3DX04 for Pocket TV panel , 128 PPI Pixel Density
4.3 Inch Sharp LCD Panel LQ043T3DX04 for Pocket TV panel , 128 PPI Pixel Density
4.3 Inch Sharp LCD Panel LQ043T3DX04 for Pocket TV panel , 128 PPI Pixel Density
4.3 Inch Sharp LCD Panel LQ043T3DX04 for Pocket TV panel , 128 PPI Pixel Density
Specifications
Brand Name :
Sharp LCD Panel
Model Number :
LQ043T3DX04
Certification :
ISO9001
Place of Origin :
Japan, Korea
MOQ :
1
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
100 PCS / DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Dot Resolution :
480(RGB)×272 (WQVGA)
Pixel Density :
128 PPI
Form Factor :
Flat Rectangle Display
Pixel Pitch :
0.198×0.198 mm (H×V)
Description

4.3 Inch Sharp LCD Panel LQ043T3DX04 for Pocket TV panel , 128 PPI Pixel Density

Panel Brand : SHARP
Panel Model : LQ043T3DX04
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 4.3 inch
Resolution : 480(RGB)×272 , WQVGA
Display Mode : ASV, Normally Black, Transmissive
Active Area : 95.04×53.856 mm
Outline : 105.5×67.2 mm
Surface : Clear, Hard coating
Brightness : 230 cd/m2 (Typ.)
Contrast Ratio : 400:1 (Typ.)
Display Colors : 16.7M (8-bit)
Response Time : 30/30 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 7S1P WLED Without Driver
Signal Interface : Parallel RGB (1 ch, 8-bit) , 40 pins
Input Voltage : 2.5/5.0V (Typ.)(VCC/AVDD)

What’s our advantage compared with other suppliers?

(1). Before shipment, we will test every LCD Screen and ensure the quality.

(2). we provide high quality lcd panels for customers all over the world.

(3) .We have DBS, ISO9001 Certifications for our Panels.

(4) .Excellent service on before-sale, on-sale and after-sale.

Packaging & Shipping for Our LCD panel

1. We will ship the LCD display panels within 1-3 workdays after receipt of payment.

2. We can ship to you by UPS/FEDEX/DHL and so some other direct international express line.

Other shipping terms can also be arranged according to specific requirements.

LQ043T3DX04 General Features

Panel Size : 4.3 inch
Dot Resolution : 480(RGB)×272 (WQVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 128 PPI
Aspect Ratio : 16:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.066×0.198 mm (H×V)
Pixel Pitch : 0.198×0.198 mm (H×V)
Weight : 50.0g (Typ.)
Surface : Clear, Hard coating
Active Area : 95.04×53.856 mm (H×V)
Bezel Area : 98.7×57.5 mm (H×V)
Outline Dimension : 105.5×67.2 mm (H×V)

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LM016LC1S07 SHARP 1.9" 96×128
LS050K3SX06A SHARP 5.0" 720×1280
LK460D3HA10 SHARP 46" 1920×1080
LK315T3HB874 SHARP 31.5" 1366×768
LK315T3HB873 SHARP 31.5" 1366×768
LQ0DZC0156 SHARP 40" 1920×1080
