Antiglare 400 cd / m² NL3224AC35-20 NEC LCD Panel for Industrial Application
Antiglare 400 cd / m² NL3224AC35-20 NEC LCD Panel for Industrial Application
Specifications
Brand Name :
NEC
Model Number :
NL3224AC35-20
Certification :
ISO9001
Place of Origin :
KOREA
MOQ :
1
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Supply Ability :
500PCS/DAY
Resolution :
320(RGB)×240 , QVGA
Input Voltage :
3.3/5.0V (Typ.)(VCC)
Contrast Ratio :
400:1 (Typ.)
Brightness :
400 cd/m² (Typ.)
Display Colors :
262K (6-bit) , CIE1931 50%
Viewing Angle :
65/65/40/65 (Typ.)(CR≥10) (L/R/U/D)
Description

Antiglare 400 cd / m² NL3224AC35-20 NEC LCD Panel for Industrial Application

NL3224AC35-20 Information

Panel Brand : NEC
Panel Model : NL3224AC35-20
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 5.5 inch
Resolution : 320(RGB)×240 , QVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 111.36×83.52 mm
Outline : 134×104.5 mm
Surface : Antiglare, Hard coating (3H), Antireflection
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 400:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 50%
Response Time : 5/25 (Typ.)(Tr/Td)
Viewing Angle : 65/65/40/65 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 2 pcs CCFL
Signal Interface : CMOS (1 ch, 6-bit) , 33 pins
Input Voltage : 3.3/5.0V (Typ.)(VCC)

We Can Do for You:

1) One-to-one service with efficient & professional support;

2) Protection of your design and all your private information;

3) We could supply different hard disk for you.

4) Quality stability, can to provide certification of products;

5) Convenient payment methods: PayPal, T/T and Western Union;

6) Speedy shipment: we could arrange the shipment within 1-3 business days.

7) Quality & Service: Our priority has always been providing our clients with great quality products and superior customer service.

8) Unbeatable Prices: We continuously strive to find ways of reducing our production costs, and passing the savings to you.

Packaging & Delivery

· Delivery Lead Time :2~3 weeks

· Minimum Order :1 pcs LCD Panel

· Supply Ability :100 PCS / Per Day

Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
ED0970C1 E Ink 9.7" 1200×825
ED097OC1 E Ink 9.7" 1200×825
ED080XC2 E Ink 8.0" 1024×768
ED080XC1 E Ink 8.0" 1024×768
ED060SC3 E Ink 6.0" 800×600
ED050SC1 E Ink 5.0" 800×600
PD035QX7 E Ink 3.5" 320×240
PW070DS6 E Ink 7.0" 480×234

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

Panel Size : 5.5 inch
Dot Resolution : 320(RGB)×240 (QVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 72 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.116×0.348 mm (H×V)
Pixel Pitch : 0.348×0.348 mm (H×V)
Surface : Antiglare, Hard coating (3H), Antireflection
Active Area : 111.36×83.52 mm (H×V)
Bezel Area : 116.4×88.5 mm (H×V)
Outline Dimension : 134×104.5 mm (H×V)
Outline Depth : 12.5±0.5 mm
Holes & Brackets : Rear mounting holes (4-M3)
Landscape or Portrait : Landscape type
Touch Panel : Without

NL3224AC35-20 NEC LCD Panel Picture
