LTM08C351S TOSHIBA 8.4 inch TN LCM 800×600 350nits CCFL TTL 30pins
LTM08C351S TOSHIBA 8.4 inch TN LCM 800×600 350nits CCFL TTL 30pins
Specifications
Brand Name :
TOSHIBA
Model Number :
LTM08C351S
Certification :
ISO9001
Place of Origin :
Japan
MOQ :
1
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
100 PCS / DAY
Delivery Time :
2-3 working days after payment confirmation
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Series :
LTM08C351
Keywords Desc. :
TOSHIBA 8.4" TN LCM 800×600 350nits CCFL TTL 30pins
Product Class :
Graphic LCD Display
Product Tags :
Color TFT-LCD,Transmissive LCD
Application :
Industrial Application
Panel Type :
LTPS TFT-LCD
Panel Composition :
LCM
Panel Size :
8.4"
Resolution :
800×600
Aspect Ratio :
4:3 (W:H)
Form Factor :
Flat Rectangle Display
Orientation :
Landscape type
Active Area :
170.4 (W) × 127.8 (H) mm (A.A)
Viewing Area :
173.4 (W) × 130.8 (H) mm (V.A)
Outline Dimension :
199.5 (W) × 149.5 (H) mm
Weight :
385g (Typ.)
LC Family :
TN
Polarizer :
Transmissive
Brightness :
350 (Typ.)
Contrast Ratio :
300:1 (Max.)
Description

LTM08C351S TOSHIBA 8.4 inch TN LCM 800×600 350nits CCFL TTL 30pins

FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange
professional sales team to follow up your case.

Packaging & Delivery
Packaging Details:
Antistatic bag + Bubble bag + Foam box + Carton box
Delivery Detail:
1-3 working days after payment confirmed

LTM08C351S Quick Details:

Panel Brand : Toshiba Matsushita
Panel Model : LTM08C351S
Panel Type : LTPS TFT-LCD , LCM
Panel Size : 8.4 inch
Resolution : 800(RGB)×600 , SVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 170.4×127.8 mm
Outline : 199.5×149.5 mm
Brightness : 350 cd/m2 (Typ.)
Contrast Ratio : 300:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 20/25 (Typ.)(Tr/Td)
Viewing Angle : 50/50/40/50 (Typ.)(CR≥10) (L/R/U/D)
Lamp Type : 2 pcs CCFL
Signal Interface : CMOS (1 ch, 6-bit) , 30 pins
Input Voltage : 3.3V (Typ.)(VDD)

Toshiba Matsushita LTM08C351S Mechanical Features

Panel Size : 8.4 inch
Dot Resolution : 800(RGB)×600 (SVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 119 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.071×0.213 mm (H×V)
Pixel Pitch : 0.213×0.213 mm (H×V)
Weight : 385g (Typ.)
Active Area : 170.4×127.8 mm (H×V)
Bezel Area : 173.4×130.8 mm (H×V)
Outline Dimension : 199.5×149.5 mm (H×V)
Outline Depth : 12.0 (Max.) mm
Holes & Brackets : Face mounting holes (4-Φ3.4)
Landscape or Portrait : Landscape type
Touch Panel : Without


Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
LTD121LA7SG (Z) TOSHIBA 12.1" 1024×768
LTD154LZ1SG TOSHIBA 15.4" 1920×1200
LTD141LA1SG TOSHIBA 14.1" 1024×768
LTD121EA43G TOSHIBA 12.1" 1024×768
LTH15C503-A TOSHIBA 15.0" 1024×768
LTM024D161 TOSHIBA 2.4" 240×320
LTM030DH60 TOSHIBA 3.0" 240×427
LTD154LZ1SG (Z) TOSHIBA 15.4" 1920×1200
LTD154EZ0HG TOSHIBA 15.4" 1920×1200
LTA140C06HF TOSHIBA 14.0" 640×480
LTM06C381 TOSHIBA 5.8" 800×480

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk

LTM08C351S Picture
