WLED Backlight Industrial G190EG01 V1 19 LCM AUO LCD Panel
WLED Backlight Industrial G190EG01 V1 19 LCM AUO LCD Panel
WLED Backlight Industrial G190EG01 V1 19 LCM AUO LCD Panel
WLED Backlight Industrial G190EG01 V1 19 LCM AUO LCD Panel
Specifications
Brand Name :
AUO
Model Number :
G190EG01 V1
Place of Origin :
taiwan
MOQ :
1
Price :
pls contact us
Payment Terms :
T/T, Western Union,PAPLY,BANK TRANSFER
Supply Ability :
1000
Delivery Time :
5-8 work days
Packaging Details :
standard Packaging
Brand :
AUO
Model :
G190EG01 V1
Diagonal Size :
19.0 inch
Type :
a-Si TFT-LCD, LCM
Pixel Format :
1280(RGB)×1024 [SXGA] 86PPI
Configuration :
RGB Vertical Stripe
Active Area :
376.32(H)×301.056(V) mm
Outline Dim. :
396(H)×324(V) ×18.3(D) mm
Description

WLED Backlight Industrial G190EG01 V1 19" LCM AUO LCD Panel

Description Of AUO LCD Panel

G190EG01 V1 (Alias: G190EG01 V.1) is a 19.0 inch diagonal a-Si TFT-LCD display screen product from AUO, with a built-in WLED backlight, With LED Driver, without touch screen. On the basis of latest version datasheet Ver1.3 which was released out on 7 1 2013, G190EG01 V1 supports display 1280(RGB)×1024 (SXGA) with aspect ratio of 5:4 (W:H), whose pixels are arranged in RGB Vertical Stripe.5(V)±0.46Kgs

AUO G190EG01 V1 Optical Features

Basic Information : Luminance (cd/m²) Viewing Angle (L/R/U/D) Response Time (ms)
350 (Typ.) 85/85/80/80 (Typ.)(CR≥10) 3.6/1.4 (Typ.)(Tr/Td)
Best View on Display Mode Contrast Ratio
- TN, Normally White, Transmissive 1000 : 1 (Typ.) (Transmissive)
Dispaly Color : Color Temperature Display Colors White Coordinate
6485K 16.7M (6-bit + Hi-FRC) X:0.313; Y:0.329
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
72% 94% 73%
DCI-P3 Coverage Rec.2020 Coverage Remarks
75% 54% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation : 1.25/1.33 (Typ./Max.)(9 points)

AUO G190EG01 V1 Mechanical Features

Panel Size : 19.0"
Pixel Features : Pixel Format Pixel Configuration Pixel Pitch (mm) Dot Pitch (mm)
1280(RGB)×1024 [SXGA] RGB Vertical Stripe 0.294×0.294 [86PPI] 0.098×0.294
Mechanical Size : Active Area (mm) Bezel Area (mm) Outline Dimension (mm) Outline Depth (mm)
376.32(H) × 301.056(V) 380.32(H) × 305.06(V) 396(H) × 324(V) 18.3 (Max.) mm
Outline Features : Form Factor Orientation Aspect Ratio Shape Style
Flat Rectangle Landscape type 5:4 (H:V) -
Mounting : Side mounting holes (4-M3) on left, right bezel
Other Detail : Weight Panel Cover Treatment
1.67Kgs (Typ.) - Antiglare, Hard coating (3H)

Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information

T320HVN02.1 CELL AUO 31.5"
M270DAN01.1 CELL AUO 27.0"
T500QVN03.3 CELL AUO 50"
T500QVN03.0 CELL AUO 50"
H546DAN07.3 AUO 5.5"
M270HVN02.3 CELL AUO 27.0"
M270HVN02.2 CELL AUO 27.0"
M270HVN02.1 CELL AUO 27.0"
M270DTN01.0 CELL AUO 27.0"
T320HVN05.7 CELL AUO 31.5"
T320HVN05.4 CELL AUO 31.5"
T215HVN01.2 CELL AUO 21.5"
B070ATN02.0 CELL AUO 7.0"
M238DAN01.3 CELL AUO 23.8"
B070AAN01.0 AUO 7.0"
M238DAN01.1 CELL AUO 23.8"
M270DAN02.0 CELL AUO 27.0"
Application Of AUO LCD Panel G190EG01 V1
1. Display Unit
2. Security Cameras
3. Cash register equipment
4. All in one machine
5. Industrial Equipment
6. Queuing machine
7. Medical Equipment
8. On-board display
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange professional sales team to follow up your case.

Our Service

1. Small quantity also can be provided.

2. New models can be updated fast.
3. We have strict QC team to make sure all products are qualified before delivery.
4. Warranty promise

5. Sourcing line for different hard disks for different brands.

WLED Backlight Industrial G190EG01 V1 19WLED Backlight Industrial G190EG01 V1 19
