8.4 Inch 800*600 AA084SC01 TFT LCD Panel For Industrial
8.4 Inch 800*600 AA084SC01 TFT LCD Panel For Industrial
Specifications
Brand Name :
Mitsubishi
Model Number :
AA084SC01
Certification :
ISO9001
MOQ :
1
Payment Terms :
T/T, Western Union,Escrow 10(we pay hkinventory escrow fee) ,Paypal
Supply Ability :
3000
Delivery Time :
1-3 Working Days
Packaging Details :
Antistatic bag, Bubble Bag, Foam Box and Carton Box
Size :
8.4 Inch
Resolution :
800×600
Brightness :
600
C/R :
1000:1
View Angle :
88/88/88/88
Colors :
262K/16.7M
Backlight :
Interface
Touchscreen :
Without
Signal Type :
LVDS (1 ch, 6/8-bit) ,Connector 20 pins
Description

8.4 Inch 800*600 AA084SC01 TFT LCD Panel For Industrial

1.Mitsubishi AA084SC01 Mechanical Features:

Screen Size : 8.4"
Pixel Features : Pixel Number Pixel Format Dot Pitch (H×V) Pixel Pitch (H×V)
800(RGB)×600, SVGA RGB Vertical Stripe 0.071×0.213 mm 0.213×0.213 mm [119PPI]
Mechanical Size : Display Area (H×V) Bezel Opening (H×V) Overall Dimension (H×V) Overall Depth
170.4×127.8 mm 174.9×132.2 mm 199.5×149 mm 9.7 (Typ.) mm
Outline Features : Form Shape Aspect Ratio (H:V) Orientation Shape Style
Flat Rectangle 4:3 Landscape type -
Other Spec : Mass Panel Cover Surface Treatment
330g (Typ.) - Antiglare, Hard coating (3H)

2.Mitsubishi AA084SC01 Optical Features:

Basic Information : Luminance Work Mode Contrast Ratio
600 cd/m² (Typ.) SWV, Normally Black, Transmissive 1000:1 (Typ.) (Transmissive)
Good View at Viewing Angle Response Time
Symmetry 88/88/88/88 (Typ.)(CR≥10) 12/12 (Typ.)(Tr/Td) (ms)
Dispaly Color : Color Temperature: Support Color Color Coordinate
6485K 262K/16.7M (6-bit / 6-bit + Hi-FRC) X:0.313; Y:0.329
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
73% 97% 75%
DCI-P3 Coverage Rec.2020 Coverage Remarks
76% 54% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Uniformity : 1.30 (Max.)(5 points)

3.Mitsubishi AA084SC01 Backlight Features:

Back-light Features: Type Position Life(Hours) Amount Shape Replacement
WLED Edge light type 100K(Typ.) - - -
Interface Features : WLED Driver State Physical Type Interface Position
With LED Driver Connector -
Interface Detail Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
JAE FI-S6P-HFE 1 pcs 6 pins 1.25 mm
WLED Driver Electrical : Input Voltage Input Current Power Consumption
12.0±1.2V 400/480mA (Typ./Max.)

4.Mitsubishi AA084SC01 Interface Features:

Signal Electrical : Input Voltage Input Current Power Consumption
3.3V (Typ.) 310/650mA (Typ./Max.) -
Interface Features : Signal Type Physical Type Interface Position
LVDS (1 ch, 6/8-bit) Connector -
Interface Detail : Brand Name Model Name Amount Pins Pin Pitch Pin Configuration 8.4 Inch 800*600 AA084SC01 TFT LCD Panel For Industrial
I-PEX 20186-020E-11F 1 pcs 20 pins 1.25 mm LVDS-20P1C8B-010H

5. FAQ:

Q1: What's the quality of your LCD Panel?

A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc. We are available to meet your different requirements.

Q2: What is your return and refund policy?

A: We provide you excellent after-sales services, and promise you 12-month warranty after shipping to assure you a stable performance.

Q3: How long is the lead time?

A: The lead time is about 2-3 working days after receipt of payment.

Q4: Do you accept sample order?

A: Yes,sample order is welcome.

Q5: How can I get the quotation?

A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
