Specifications
Brand Name :
Olycom
Model Number :
IM-PC111FE
Certification :
CE RoHS FCC ISO9001
Place of Origin :
Guangdong, China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
T/T, PayPal
Supply Ability :
5000pcs/month
Delivery Time :
3~5 working days
Packaging Details :
1pc in a box
Product name :
2 port Fiber Media Converter
Power Adapter Voltage :
DC48V
Data Rate :
10/100Mbps
PoE Output Power :
15.4W/30W
Sample :
Available
Description

Outdoor POE switch Fast Ethernet 2 port 10/100Mbps 1 RJ45+1 fiber sfp Fiber Media Converter


Key Features of Fast Ethernet Switch

  • Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable.
  • IEEE 802.3af /at power on to 1 RJ45 port
  • 1 x 10/100Mbps Auto-sensing RJ45 port
  • 1 x 100Mbps fiber port
  • 6KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 1000Base-TX compliant
  • Max power to15.4W under af standard, 30W under at standard to each PoE port
  • Detect the PoE models of electrical equipment.
  • A store-and-forward switching mechanism
  • Operating environment temperature:-40 ° ~75 ° c

Specification of Industrial Fiber Media Converter

Product Name 10/100Mbps Industrial POE Fiber Media Converter (1F+1TP)
Model No. IM-PC111FE
Port

1 x 100Mpbs fiber port
SM:1310nm/1550nm,20Km
1490nm/1550nm,40~120Km
MM:1310nm,2Km
1x10/100M UTP RJ45(Support MDI/MDIX auto-sensing)
Switching features

Transmission mode:storage and forward
System bandwidth:40Gbps (non-traffic jam)
Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)
100BASE-TX: CAT5 or above shielded twisted pair(≤100m)
Fiber port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs Power, network, fiber
Power supply

POE power supply input voltage: 48V (max 52V),
Single PoE power supply output power: 15.4W (port 1)
(802.3at standards required special instructions)
Environment

Working temperature:-40°～ 75°C
Storage temperature:-40°～ 85°C
Working humidity:10%～90%,non-condensing
Storage humidity:10%～95%,non-condensing
Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A
EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8
Traffic Control:NEMA-TS2
Vibration:IEC 60068-2-6
Freefall:IEC 60068-2-32
Shock:IEC 60068-2-27
Rail Traffic:EN 50121-4
Safety

CE Mark ,commercial
CE/LVD EN60950
Mechanical information

Shell:Corrugated metal shell
Safety class:IP40
Dimension: 113.8 x 93 x 34.9mm
Mounting method:Din-rail mounting
Warranty Replacement within 1 year; 3 years repairing

Outdoor POE Switch Fast Ethernet 2 Port 10/100Mbps 1 RJ45+1 Fiber Sfp Fiber Media Converter


Packing box of switch

Outdoor POE Switch Fast Ethernet 2 Port 10/100Mbps 1 RJ45+1 Fiber Sfp Fiber Media Converter

  • Put the product in an ESD Bag, then placed in PE foams with outer carton packaging.
  • The standard packing usually contains a main device, a warranty card and a user manual.
  • Packing box dimension for 1pc: 23*16.5*5.8cm
  • 40pcs in a packing box of 67*33*47cm dimension.
