Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V
Specifications
Brand Name :
Olycom
Model Number :
IM-MC110GE-ST
Certification :
CE RoHS FCC ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T, PayPal
Supply Ability :
3000pcs/month
Delivery Time :
3~7 working days
Packaging Details :
1pc in a carton, 0.45kg/pc gross weight
Product name :
Gigabit industrial media converter
Dimension :
114*93*35mm
Weight :
0.35kg, net weight
Warranty :
3 years
Rate :
10/100/1000M
Feature :
Unmanaged, Non-POE
Description

Gigabit Industrial Unmanaged Fiber Media Converter

Introduction to Industrial Media Converter

  • IM-MC110GE series is the 10/100/1000 Mbps industrial unmanaged fiber switch
  • operating temperature -40 ℃ to + 75 ℃
  • support wide voltage dual power input
  • meet IP40 protection degree and EMC industrial grade requirements
  • DIN rail installation
  • pass through dangerous environmental certification and comply with FCC and CE standards

Key Features of Rugged Ethernet Optic Converter

  • 1 x 10/100/1000Mbps Auto-sensing RJ45 ports
  • 1 x 1000Mbps ST duplex fiber port
  • 6 KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • A store-and-forward switching mechanism

Specification of Fiber Optic Ethernet Converter

Product Name 10/100/1000Mbps Industrial Fiber Media Converter (1TP+1F)
Model No. IM-MC110GE-ST
Port

1 x 1000Mpbs port

SM:1310nm/1550nm, 20Km

MM:1310nm, 2Km; 850m, 500m

1x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Switching features

Transmission mode: storage and forward

System bandwidth: 4Gbps (non-traffic jam)

Packet Forwarding Rate: 2.976Mpps

MAC: 4K

Queue Buffer: 1.75M
Network media

10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)

100BASE-TX: CAT5 or above shielded twisted pair(≤100m)

SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km
LEDs Power, network, fiber
Power supply

Input voltage: DC 12-52V

No-load power:5W

Reverse connection: support
Environment

Working temperature:-40°～75°C

Storage temperature:-40°～ 85°C

Working humidity:10%～90%,non-condensing

Storage humidity:10%～95%,non-condensing
Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8

Traffic Control:NEMA-TS2

Vibration:IEC 60068-2-6

Freefall:IEC 60068-2-32

Shock:IEC 60068-2-27

Rail Traffic:EN 50121-4
Safety

CE Mark ,commercial

CE/LVD EN60950
Mechanical information

Shell:Corrugated metal shell

Safety class:IP40

Dimension: 113.8 x 93 x 34.9mm

Mounting method:Din-rail mounting

Weight: 0.35kg
Warranty Replacement within 1 year; 3 years repairing

Size of Unmanaged media converter

Mini Rugged Unmanaged Media Converter Gigabit ST Fiber 30km Dual DC12V

FAQ

1 Q: What is your lead time?

A:It usually takes 2~4 working days to produce and then will send goods.

2 Q: How will you send my goods?

A: We will send the goods by DHL, TNT, UPS or FEDEX, please check the delivery details by the tracking number.

3 Q: Please tell me something about your MOQ

A: Our MOQ is 1 Pcs/Pair based on USD or EUR terms.

4 Q: Something about pricing.

A: Good quality components for our products. Low prices for big and repeat orders.
