Specifications
Brand Name :
Olycom
Model Number :
OM610-8V↑WT/R
Certification :
CE RoHS FCC
Place of Origin :
Shenzhen, China
MOQ :
1 Pair
Price :
Negotiable
Payment Terms :
T/T, Paypal
Supply Ability :
500 Pairs per week
Delivery Time :
5~8 working days
Packaging Details :
1 pair in a carton, 1.00kg/piece
Video :
BNC port, PAL NTSC Secam compliant
Channel :
8ch, standalone type
Power input :
DC5V1A
Dimension :
179mm*130.5mm*50mm
Description

8 Port analog video optic converter multiplexer

Model: OM610-8V↑WT/R. We support your model

Product Overview

Olycom OM610-8V↑WT/R optical video transmitter and receiver transmit 8ch video signals on optical fiber.

On 9/125um Single mode fiber its working distance is 20Km to 80KM while on multimode fiber it’s 1Km.

Key Features

  • Robust metal casing
  • Lightning-proof solution
  • Low optical link loss – max 30dB
  • Without EMI, RFI and ground loop
  • Bi-di transmission on 1 fiber with WDM
  • Hot plug-and-play with switch power supply
  • Available in standalone and 3U rack systems

Parameters

Optical

Wavelength

1310nm/1550nm

Output Power

-8~3dBm

Optic fiber

Single mode (9/125um) 20Km

Multimode (50/125um) 1Km, ( 62.5/125um) 500m

Receiving sensitivity

-30dBm

Interface

FC standard, ST/SC optional

Video

Channel Quantity

8ch, from camera to control center

Compatible Systems

NTSC/PAL/SECAM

Impedance/Voltage

BNC 75Ω (unbalanced) / 2.0Vp-p

Differential Gain

< ±1%

Differential Phase

< ±1

S/N ratio

>60dB(weighting)(8 bit)

Interface

BNC

Electrical. Environmental. Mechanical

Operating voltage

DC5V1A

Operating temperature

-20℃～+70℃

Storage temperature

-45℃～+85℃

Humidity

0~95%non-condensing

Dimension-standalone

179mm*130.5mm*50mm

Weight

0.66kg/piece (Net Weight), 1.00 kg/piece (Gross Weight)

Application

  • Expressway security protection and toll station system
  • City traffic monitoring system
  • Building and campus monitoring system
  • Industrial monitoring (airport, chemical plant, railway, etc.)
  • Military monitoring (frontier defense, national defense)
  • Electronic power oil field, TV station program broadcasting
  • Gymnasium (live video and audio transmission)

8 Port Analog Video Digital Optical Converter Multiplexer Over Coaxial Cable DC5V

Ordering Details

OM610-8V↑WT/R-FC20

8ch video Tx, single-mode, single fiber, 20Km, FC

OM610-8V↑MT/R-FC1

8ch video Tx, multi-mode, single fiber, 1Km, FC

FAQ

1. Are you a manufacturer?

Yes, we have our production line and R&D team.

Please visit us via below VR link to see our office and production area.

https://www.ecer.com/corp/uuu5b8d-industrialnetworkswitch/vr.html

2. Do you accept sample order?

A: Yes. Sample order to check our services and quality.

3. Can I have any discounts?

A: Discounts will be given to repeat orders, regular clients and discount products.

4. What incoterms do you support?

We are an EXW factory, EXW term is our focus.

Sometimes we do FOB/CIF for bulk orders, this depends on cases. Please talk with us for more information.
